Compact white PoE splitter with RJ45 ports and USB-C power output

Ransanx TYPEC0504G powerline networking 5V 4A Gigabit PoE Splitter Type-C

SKU CH-KBGE-4D324 MPN TYPEC0504G

Splits PoE into 5V 4A Type-C power plus Gigabit data for non-PoE devices

  • Interfaceusb_c
  • Powerline Speeds1000 megabits_per_second
  • Connection TypeIEEE 802.3af/at
  • Connection Speeds1000 megabits_per_second
  • Features1pcs 5V 4A Gigabit Poe Splitter
  • Package Contents1pcs 5V 4A Gigabit Poe Splitter
  • Delivers 5V 4A power via Type-C from standard PoE
  • Gigabit data pass-through at 1000 megabits per second
  • Compliant with IEEE 802.3af/at up to 30W input
  • Built-in isolation, short-circuit and overvoltage protection
  • Operates reliably from -40 to 70 degrees Celsius

PoE splitter with Type-C output

The Ransanx TYPEC0504G separates power and data from a single Ethernet cable. It accepts a 48 V DC PoE input compliant with IEEE 802.3 af/at and delivers 5 V at 4 A through a USB-C connector while passing Gigabit data through its RJ45 ports. The unit operates from -40 °C to 70 °C with isolation, short-circuit and over-voltage protection.

Installers powering USB-C devices over Ethernet

Suited for deployments where a Raspberry Pi 4 or 5, IP camera, tablet or similar 5 V USB-C device needs both power and network connectivity without a local mains outlet. Not intended for equipment requiring voltages other than 5 V, for endpoints needing more than 30 W, or for networks limited to 100 Mbps cabling.

5 V 4 A USB-C power from IEEE 802.3 af/at PoE

The decisive specification is the 5 V 4 A output delivered through the Type-C port when fed by a standard 48 V PoE source. This determines whether the splitter can run a specific USB-C device such as a Raspberry Pi 5 or an IP camera without an additional power adapter.

Highlights

  • Delivers 5V 4A power via Type-C from standard PoE
  • Gigabit data pass-through at 1000 megabits per second
  • Compliant with IEEE 802.3af/at up to 30W input
  • Built-in isolation, short-circuit and overvoltage protection
  • Operates reliably from -40 to 70 degrees Celsius

Specifications

BrandRansanx
Interfaceusb_c
Powerline Speeds1000 megabits_per_second
Connection TypeIEEE 802.3af/at
Connection Speeds1000 megabits_per_second
Features1pcs 5V 4A Gigabit Poe Splitter
Package Contents1pcs 5V 4A Gigabit Poe Splitter

Questions about this item

What is the maximum ambient temperature the splitter can operate in continuously?

The unit is rated for continuous operation up to 70 °C and storage up to 85 °C, both non-condensing.

How much power does the splitter draw from the PoE source when delivering 5 V at 4 A?

The input accepts 48 V DC at 0.6 A, compliant with IEEE 802.3 af/at up to 30 W.

Which PoE standard must the switch or injector support for this splitter to work?

The splitter requires a PSE that meets IEEE 802.3 af/at (30 W) and supplies 44–57 V on the RJ45 input.
