Black compact PA amplifier with front panel controls and LED indicators

Pyle

Pyle PMSA126BU 500W PA speaker 70V/100V Bluetooth FM USB/SD

SKU CH-K8R7-FQ9VH MPN PMSA126BU

Compact PA amplifier delivers 500 W across 70 V, 100 V and low-impedance outputs with Bluetooth streaming, FM radio and USB/SD playback up to 32 GB

  • Color/FinishBlack
  • TypeAccessory
  • IndicatorAudio Output Level LED Indicator Lights
  • Power Supply120V AC, 60Hz (12V DC Input available)
  • Additional SpecificationSupports MP3/WAV/WMA file types USB/SD Flash Memory Support
  • FeatureBuilt-in Bluetooth for wireless streaming FM Radio with Digi
  • Built-in Bluetooth streams audio wirelessly up to 40 ft
  • 500 W MAX output drives 4/8/16 Ω and 70V/100V lines
  • Dual ¼" mic inputs with independent rotary volume control
  • Plays MP3/WAV/WMA from USB or SD cards up to 32 GB
  • Compact 10.2 x 11.8 x 3.14 in desktop design for easy transport

Compact PA Amplifier with 70V/100V Output

The Pyle PMSA126BU is a desktop public-address amplifier that delivers up to 500 W maximum power through 70 V, 100 V, 4 Ω, 8 Ω or 16 Ω speaker lines. It includes built-in Bluetooth streaming, an FM radio with digital display, USB and SD card readers for MP3, WAV and WMA files, plus dual ¼-inch microphone inputs and a button-activated siren alarm.

Suited for installed voice

This unit fits installations that require constant-voltage speaker lines and simple source switching from a single rack-mountable box. It is not for users who need multi-zone matrix routing, networked audio control, or a separate mixer with EQ and effects processing.

70 V and 100 V constant-voltage speaker outputs

The amplifier drives distributed speaker lines at 70 V or 100 V directly, letting you run long cable runs without impedance matching. If your system uses only low-impedance speakers, the 4 Ω, 8 Ω and 16 Ω terminals are also available.

Highlights

  • Built-in Bluetooth streams audio wirelessly up to 40 ft
  • 500 W MAX output drives 4/8/16 Ω and 70V/100V lines
  • Dual ¼" mic inputs with independent rotary volume control
  • Plays MP3/WAV/WMA from USB or SD cards up to 32 GB
  • Compact 10.2 x 11.8 x 3.14 in desktop design for easy transport

Specifications

BrandPyle
ModelPMSA126BU
Color/FinishBlack
TypeAccessory
Part NumberPMSA126BU
IndicatorAudio Output Level LED Indicator Lights
Power Supply120V AC, 60Hz (12V DC Input available)
Additional SpecificationSupports MP3/WAV/WMA file types
USB/SD Flash Memory Support up to 32GB
FeatureBuilt-in Bluetooth for wireless streaming
FM Radio with Digital LED display
Dual Microphone Inputs (1/4” jacks)
Up to 40' Bluetooth range
Compact design for easy transport
Remote Control included
Height3.14 inches
Width10.2 inches
Depth11.8 inches
Package ContainPA Amplifier
Remote Control
FM Antenna

Questions about this item

What size rack or shelf space does the 10.2-inch wide by 11.8-inch deep amplifier need?

The unit measures 10.2 inches wide, 11.8 inches deep and 3.14 inches high, so allow at least that footprint plus cable clearance on a shelf or in a 2U rack opening.

How do I connect passive speakers to the 70V, 100V, 4, 8 or 16 ohm terminals, and what wiring mistake is common?

Match each speaker’s impedance or voltage tap to the corresponding output terminal; a frequent error is connecting a 70V line to the 4/8/16 ohm posts instead of the 70V/COM pair.

Which consumable items will need replacement over time on this amplifier?

The FM antenna wire, remote-control battery and any connected microphone cables are the parts most likely to wear out or get lost during regular use.
