Aluminium 7.5-degree F34 truss corner, silver finish, conical couplers, diagonal braces

ProX

ProX 7.5 Degree F34 Truss Corner

SKU CH-9TBP-B129M

A 7.5-degree aluminium truss corner with TÜV-welded joints, 50 mm tube diameter, 2 mm wall thickness and included connecting hardware for angled stage structures

  • Certified TUV welders ensure structural integrity
  • 5-degree angle enables creative roof designs
  • 6082-T6 aluminum alloy provides high tensile strength
  • Conical coupling system allows quick genderless assembly
  • 2 mm wall thickness maintains excellent weight loading

7.5 Degree F34 Truss Corner

The ProX 7.5 Degree F34 Truss Corner is a fixed-angle connector fabricated from aluminum alloy EN AW-6082 T6 for professional stage and lighting structures. Certified TUV welders assemble each unit with integrated diagonal bracing to maintain structural rigidity. Supplied connecting hardware allows rapid assembly with minimal tools for touring crews and permanent installers alike.

Sustained Load Behaviour

The 2 mm wall thickness and 20 mm diagonal bracing distribute forces evenly across the 50 mm outer diameter chords during continuous loading. Conical couplers keep chord alignment precise at stress points, reducing local deformation over long production runs. Genderless coupling geometry maintains consistent load paths whether the corner is used singly or repeated in a curved roof array.

Upgrade Path

This corner replaces standard 90-degree box connectors when a design requires a shallow 7.5 degree turn or a compound curve. The jump is justified when a roof structure or decorative grid demands angles that normal orthogonal units cannot achieve without custom fabrication. Builders needing tighter radii or different angle increments must source alternative fixed or adjustable corners.

Highlights

  • Certified TUV welders ensure structural integrity
  • 5-degree angle enables creative roof designs
  • 6082-T6 aluminum alloy provides high tensile strength
  • Conical coupling system allows quick genderless assembly
  • 2 mm wall thickness maintains excellent weight loading

Specifications

No published specifications for this item yet.

Questions about this item

How much does the 8 lb truss corner add to the load on my rigging points when used all day?

The corner weighs 8 lbs and is built from EN AW-6082 T6 aluminum with 2 mm wall thickness, so it adds minimal static load to overhead points during extended use.

What hardware must I already own to connect this 7.5 degree corner into an F34 truss run?

The unit ships with its own connecting hardware and uses the ProX conical coupling system, so you only need matching F34 truss sections with the same genderless couplers.

Will the 50 mm outer-diameter tubes on this corner line up with older F34 pieces I already have?

Yes, the 50 mm OD chords and 20 mm diagonal braces follow the standard F34 profile, so they align with existing F34 truss of the same specification.
