Rectangular sealed lead-acid battery cartridge, black plastic casing, recessed terminals on top

PowerWarehouse

PowerWarehouse APCRBC116-PW replacement battery cartridge #116

SKU CH-ZQHR-1F7HQ

Replacement sealed lead-acid battery cartridge for APC SMX750 and SMX1000 UPS models, 16.94" L x 6.19" W x 3.00" H, 25.9 lbs

  • CompatibilitySMX1000, SMX1000I, SMX1000US, SMX750, SMX750CNC, SMX750I, SM
  • Dimension16.94" L x 6.19" W x 3.00" H
  • Weight25.9 lbs
  • Ready for SMX1000 and SMX750 UPS units
  • Sealed lead-acid design prevents leaks
  • Direct replacement for APCRBC116 and RBC116
  • Measures 16.94" L x 6.19" W x 3.00" H
  • Weighs 25.9 lbs for stable mounting

Replacement Cartridge for SMX UPS

This sealed lead-acid cartridge replaces Battery Cartridge #116 in APC SMX750 and SMX1000 series UPS units. It fits models including SMX750I, SMX750NC, SMX1000US and the CNC, INC and NMC variants. The unit arrives new and ready to install without extra configuration.

Sealed Lead-Acid Chemistry Limits

The maintenance-free design prevents electrolyte leakage during normal operation. Capacity degrades with age and temperature, so runtime will shorten gradually over the service interval. No user-serviceable cells are inside; the whole cartridge is swapped when backup time falls below requirements.

Dimensions and Mounting Impact

The cartridge measures 16.94" L x 6.19" W x 3.00" H and weighs 25.9 lbs, so two people or a lift aid are advisable when sliding it into the UPS chassis. Terminal orientation matches the original RBC116, ensuring the existing wiring harness connects without adapters or cable routing changes.

Highlights

  • Ready for SMX1000 and SMX750 UPS units
  • Sealed lead-acid design prevents leaks
  • Direct replacement for APCRBC116 and RBC116
  • Measures 16.94" L x 6.19" W x 3.00" H
  • Weighs 25.9 lbs for stable mounting

Specifications

BrandPowerwarehouse
ModelAPCRBC116-PW
Part NumberAPCRBC116-PW
CompatibilitySMX1000, SMX1000I, SMX1000US, SMX750, SMX750CNC, SMX750I, SMX750INC, SMX750NC, SMX750-NMC, SMX750US
Dimension16.94" L x 6.19" W x 3.00" H
Weight25.9 lbs

Questions about this item

Which UPS models does this cartridge replace?

It replaces Battery Cartridge #116 in APC SMX750 and SMX1000 series units, including SMX750I, SMX750US, SMX1000I and SMX1000US.

How long will the 25.9 lb sealed lead-acid pack run my SMX1000 under load?

Runtime depends on the connected load; the cartridge restores the original capacity the SMX1000 was designed for.

What connection standard does the cartridge use inside the UPS?

It uses the standard APC battery-cartridge interface that slides into the SMX750 or SMX1000 battery compartment.
