Power Drive C4016X1 Chain Coupling Sprocket 16T 1 in Bore
Chain coupling sprocket with 16 teeth, 1-inch round keyed bore, and 4.14 hp at 100 RPM
- TypeDrain Components
- 16-tooth chain coupling for 1/2 in pitch drives
- 1 in round keyed bore with 1/4 in keyway
- Rated 4.14 hp at 100 rpm and 16.9 hp at 4,000 rpm
- Tolerates 1 degree angular and 0.005 in parallel misalignment
- Supports 0.06 in axial motion up to 150 °F
Chain Coupling Sprocket for Power Transmission
The Power Drive C4016X1 is a chain coupling sprocket designed for mechanical power transmission systems. It suits engineers and maintenance technicians who need a direct replacement for worn sprockets on existing chain drives. The component connects rotating shafts using a standard roller chain. Buyers who need a complete coupling assembly with cover or a different chain size will need additional parts.
16-Tooth Profile for #40 Chain
This sprocket has 16 teeth cut for ANSI #40 chain with a 1/2 inch pitch. The round keyed bore measures 1 inch in diameter with a 1/4 inch keyway width and 1/8 inch keyway depth. At 100 RPM it transmits 4.14 hp, rising to 16.9 hp at 4,000 RPM. Maximum operating temperature is 150 degrees F.
Direct Shaft Mounting
The round keyed bore slides onto a matching shaft and locks with a standard key. Installation requires aligning shafts within 1 degree angular and 0.005 inch parallel misalignment. Axial float of 0.06 inch must be accommodated. The matching cover uses part number AL40. Exceeding alignment limits accelerates chain and sprocket wear.
Highlights
- 16-tooth chain coupling for 1/2 in pitch drives
- 1 in round keyed bore with 1/4 in keyway
- Rated 4.14 hp at 100 rpm and 16.9 hp at 4,000 rpm
- Tolerates 1 degree angular and 0.005 in parallel misalignment
- Supports 0.06 in axial motion up to 150 °F
Specifications
| Type | Drain Components |
|---|---|
| Brand | Power Drive |
| Model | C4016X1 |
Questions about this item
What does 4.14 hp at 100 rpm mean for a machine using this sprocket?
It shows the power the coupling can transmit continuously at low speed; at 100 rpm the rating is 4.14 hp.
How does the 1/2 in chain pitch limit the setup?
The sprocket only meshes with ANSI 40 chain on a 1/2 in pitch, so chain and mating sprocket must match that pitch.
What shaft and keyway dimensions are required to mount this sprocket?
It fits a 1 in round shaft with a 1/4 in wide by 1/8 in deep keyway.
