Ten amber mini banana plugs with gold-plated brass bodies and threaded studs

Pomona Electronics

Pomona Electronics 3276 Mini Banana Plug Amber PK10

SKU CH-MMD5-M8KYH

Pack of ten miniature banana plugs rated 30 V AC or 60 V DC with gold-plated brass contacts and solder turret for secure wiring

  • Color MappingAmber
  • TypeMechanical Connectors
  • Pack of 10 mini banana plugs for multiple connections
  • Gold-plated beryllium copper contacts ensure low resistance and long insertion life
  • Solder turret allows secure wire attachment
  • Threaded stud enables fast panel mounting
  • Rated for 30 VAC / 60 VDC and 5 A maximum current

Mini banana plugs for electronics testing

This pack contains ten Pomona Electronics 3276 miniature banana plugs in amber. They are designed for low-voltage test leads, breadboard wiring and panel-mount connections in bench or prototype work. The gold-plated beryllium copper spring provides low contact resistance over many insertion cycles.

Gold-plated brass bodies rated for continuous use

Each plug carries a maximum current of 5 A at up to 30 VAC or 60 VDC and withstands 500 V dielectric testing. The brass body and gold finish resist oxidation during sustained bench sessions, while the beryllium copper spring maintains tension without permanent set.

Solder turret and threaded stud for secure mounting

A solder turret accepts wire leads for permanent attachment and the included threaded stud allows fast panel mounting through chassis holes. The one-inch overall length keeps connections compact in crowded fixtures. Buyers needing shrouded or high-voltage connectors will require a different product.

Highlights

  • Pack of 10 mini banana plugs for multiple connections
  • Gold-plated beryllium copper contacts ensure low resistance and long insertion life
  • Solder turret allows secure wire attachment
  • Threaded stud enables fast panel mounting
  • Rated for 30 VAC / 60 VDC and 5 A maximum current

Specifications

BrandPOMONA
Color MappingAmber
TypeMechanical Connectors

Questions about this item

How much heat does the 5 A current rating generate during continuous use?

At the 5 A rating the gold-plated beryllium copper contacts keep resistance low, so heat rise stays minimal even during all-day operation.

What wire gauge and soldering tools are needed to attach leads to the solder turret?

The turret accepts standard hook-up wire; a soldering iron and rosin-core solder are all that is required to make a secure joint.

Will the 2 500 V insulation withstand legacy 30 VAC or 60 VDC test equipment safely?

Yes, the 2 500 V maximum voltage rating provides a wide safety margin above 30 VAC and 60 VDC legacy gear.
