Pomona Electronics 1325-0 Banana Plug 30VAC 60VDC Black PK10
Pack of ten black banana plugs rated 30 V AC / 60 V DC with 15 A current capacity and set-screw wire entry up to 0.12 in
- TypeAssortments & Kits
- Nickel-plated contacts deliver low-resistance connections
- 15 A current rating supports demanding test leads
- Cross-hole entry accepts wire up to 0.12 in
- Set-screw fastening enables tool-only assembly
- Pack of 10 plugs covers multiple projects
Test leads for audio and electronics
Pomona 1325-0 banana plugs connect test leads and jumpers in audio and general electronics work. The pack contains 10 black plugs with a nickel-plated brass body and beryllium-copper contacts rated for 15 A continuous current. A cross-hole wire entry accepts conductors up to .12 in diameter and a set screw secures the wire with a flat-blade screwdriver.
Fits standard banana jacks on instruments
Each plug mates with standard 4 mm banana jacks found on multimeters, power supplies and binding posts. The nickel plating resists tarnish for low contact resistance over repeated insertions. No soldering is required; the set screw allows quick assembly and rework of test leads on the bench or in the field.
Rated 30 VAC and 60 VDC for sustained use
The plugs are rated for 30 VAC and 60 VDC maximum working voltage while carrying the full 15 A rating. Insulation and materials maintain performance during extended measurement sessions without overheating. The 1 1/2 in length keeps the connection compact inside crowded test setups.
Highlights
- Nickel-plated contacts deliver low-resistance connections
- 15 A current rating supports demanding test leads
- Cross-hole entry accepts wire up to 0.12 in
- Set-screw fastening enables tool-only assembly
- Pack of 10 plugs covers multiple projects
Specifications
| Brand | POMONA |
|---|---|
| Type | Assortments & Kits |
Questions about this item
How much continuous current can each banana plug carry before it overheats?
Each plug is rated for a maximum current of 15 A, which is the limit you will reach first under sustained use.
Does the nickel-plated brass body get noticeably warm when the plug is passing its rated 15 A all day?
The nickel-plated brass body and beryllium copper contact are designed for low contact resistance, so heat rise at the full 15 A rating stays minimal during continuous operation.
What wire diameter do I need to have on hand for the cross-hole entry to accept it?
The cross-hole wire entry fits wires up to 0.12 in (3 mm) in diameter, and a flat-blade screwdriver is required to tighten the set screw.
