White PVC solenoid valve with compact inline body and coil enclosure

Plast-O-Matic

Plast-O-Matic EASMT5V16W24-PV 120V AC Solenoid Valve Trap

SKU CH-23X9-B2MH6 MPN EASMT5V16W24-PV

A 120V AC solenoid valve with PVDF body and FKM seals for inline drain control

  • TypeDrain Components
  • Normally closed operation prevents backflow when power is off
  • 120V AC supply matches standard mains voltage
  • PVDF body resists aggressive chemicals and high temperatures
  • FKM seals withstand oil and solvent exposure
  • 2 Cv rating delivers high flow capacity

Solenoid Valve for 120V AC Systems

The Plast-O-Matic EASMT5V16W24-PV is a two-way, normally closed inline valve built for 120V AC supply. Its PVDF body and FKM seals suit chemical-handling duties in industrial and laboratory piping. The 3/4-inch nominal pipe size and 1/2-inch orifice fit standard process lines. A 3.2 Cv rating indicates the flow capacity available for system design.

Pressure and Media Constraints

The coil enclosure is watertight without a junction box, simplifying installation in wet environments. Maximum operating pressure differential for air or inert gas is not rated by the manufacturer, so the engineer must verify suitability against system conditions. Fuel gas and fuel oil service are listed as not applicable, limiting the valve to compatible fluids only. The 60 Hz AC coil requires stable mains frequency for reliable actuation.

Flow Capacity and Sizing Headroom

A Cv of 3.2 defines the valve’s flow coefficient for water at 1 psi pressure drop, providing a basis for sizing calculations. This capacity handles moderate flow rates in 3/4-inch piping without excessive restriction. Systems demanding higher throughput or pressure drops beyond the unpublished limits will require a larger orifice or alternative valve series. The fixed 120V AC voltage and normally closed function determine the control scheme and fail-safe behaviour.

Highlights

  • Normally closed operation prevents backflow when power is off
  • 120V AC supply matches standard mains voltage
  • PVDF body resists aggressive chemicals and high temperatures
  • FKM seals withstand oil and solvent exposure
  • 2 Cv rating delivers high flow capacity

Specifications

TypeDrain Components
BrandPlast-O-Matic
ModelEASMT5V16W24-PV

Questions about this item

Which Plast-O-Matic EASMT5V16W24-PV version should I choose for a 120V AC supply?

The model shown operates on 120V AC at 60 Hz and is built with a PVDF body, FKM seals and a 1/2 in orifice, so it matches standard North American mains without modification.

What does the 3.2 Cv rating mean once the valve is installed in my piping?

A Cv of 3.2 indicates the flow capacity: approximately 3.2 US gallons per minute of water at a 1 psi pressure drop across the 3/4 in nominal pipe connection.

How does the 120V AC coil interface limit the valve in practice?

The coil is rated for 120V AC, 60 Hz without a junction box and in a watertight enclosure, so it must be wired to a matching AC supply and cannot be driven from DC or lower-voltage control circuits.
