Grey handheld current probe PT-3510 with 20mm jaws and BNC cable

Pintech

Pintech PT-3510 AC/DC current probe 1000A 5MHz measurement tool

SKU CH-41PC-V1PXT MPN PT-3510

Measures AC and DC current up to 1000 A with 5 MHz bandwidth and ±2% accuracy using a 20 mm jaw and standard BNC connection

  • Selling UnitEach
  • TypeElectrical Testing & Measuring
  • Accuracy±2%
  • Standards/CertificationsCE
  • Measures DC and AC currents up to 1000 A peak with 5 MHz bandwidth
  • ±2 % accuracy backed by CE certification for reliable readings
  • 20 mm jaw opening fits most conductors without rewiring
  • Standard BNC connector works with any oscilloscope input
  • Advanced magneto-electric sensor captures fast transients with 70 ns rise time

High-frequency current probe for oscilloscopes

The PT-3510 measures AC and DC currents up to 1000 A peak with a 5 MHz bandwidth. Its ±2 % accuracy and 70 ns rise time capture fast transients for power-electronics, automotive and industrial diagnostics. A standard BNC connector makes it compatible with any oscilloscope input.

Clamp-on design with 20 mm jaw opening

The probe clamps around conductors up to .79 inch diameter without breaking the circuit, freeing bench space and eliminating shunt resistors. Power is drawn from the oscilloscope through the BNC cable, so no separate supply is needed. The 500 g body stays light during extended test sessions.

Replaces invasive shunts and lower-bandwidth clamps

Moving from a resistive shunt or a sub-MHz probe removes insertion loss and extends measurable slew rates. The jump is worth it when signals exceed 350 A rms or contain edges faster than 70 ns, while users needing only steady low-level DC below 200 mA will not benefit.

Highlights

  • Measures DC and AC currents up to 1000 A peak with 5 MHz bandwidth
  • ±2 % accuracy backed by CE certification for reliable readings
  • 20 mm jaw opening fits most conductors without rewiring
  • Standard BNC connector works with any oscilloscope input
  • Advanced magneto-electric sensor captures fast transients with 70 ns rise time

Specifications

BrandPINTECH
ModelPT-3510
Selling UnitEach
TypeElectrical Testing & Measuring
Accuracy±2%
Standards/CertificationsCE

Questions about this item

What is the maximum continuous current the PT-3510 can measure before saturation?

The probe handles 350A rms continuous current. Above that level the core saturates and accuracy degrades.

How much noise does the probe add during all-day operation?

Specified noise is 200mA rms, so long captures stay clean without extra filtering.

Which oscilloscope input does the PT-3510 require?

A standard BNC connector on the scope is all that is needed; the probe ships with the BNC cable.
