Pintech P6028A high-voltage probe, slender grey body, BNC connector end

Pintech

Pintech P6028A 28kV DC 20kV AC 75MHz 1000:1 measurement tool

SKU CH-6A86-JQ46F MPN P6028A

High-voltage oscilloscope probe measures up to 28 kV DC or 20 kV AC with 1000:1 attenuation and 75 MHz bandwidth

  • Size/Dimensions80*80*320 mm
  • AC Voltage15kV
  • DC Voltage28kV
  • Item Count1 Pack
  • Selling UnitEach
  • TypeElectrical Testing & Measuring
  • Measure up to 28 kV DC safely with 1000:1 attenuation
  • Verify AC signals to 20 kV RMS with 3 % accuracy
  • Capture fast transients using 75 MHz bandwidth and 5.3 ns rise time
  • Connect to any oscilloscope via standard BNC connector
  • Compact 320 mm probe handles easily with 500 MΩ input impedance

High-Voltage Oscilloscope Probe 28 kV DC

The PINTECH P6028A is a high-voltage probe designed for oscilloscope measurements up to 28 kV DC and 20 kV AC RMS. It provides a 1000:1 attenuation ratio and a bandwidth of DC to 75 MHz. The unit features a standard BNC connector for direct connection to any oscilloscope.

Engineers measuring high-voltage signals.

This probe suits engineers and technicians who need to safely capture high-voltage waveforms in power electronics, industrial equipment or automotive systems. The 500 MΩ input impedance and 1.7 pF capacitance minimise circuit loading. Buyers requiring measurement of low-level logic or sensor voltages should select a standard passive probe instead.

1000:1 attenuation ratio defines safe measurement

The fixed 1000:1 attenuation ratio is the critical specification that determines whether this probe matches your oscilloscope input range and the voltage levels under test. It reduces a 28 kV signal to 28 V at the scope input. Verify that your instrument accepts this attenuation factor and the resulting voltage before purchase.

Highlights

  • Measure up to 28 kV DC safely with 1000:1 attenuation
  • Verify AC signals to 20 kV RMS with 3 % accuracy
  • Capture fast transients using 75 MHz bandwidth and 5.3 ns rise time
  • Connect to any oscilloscope via standard BNC connector
  • Compact 320 mm probe handles easily with 500 MΩ input impedance

Specifications

BrandPINTECH
ModelP6028A
Size/Dimensions80*80*320 mm
AC Voltage15kV
DC Voltage28kV
Item Count1 Pack
Selling UnitEach
TypeElectrical Testing & Measuring
Accuracy=3%
Standards/CertificationsCE

Questions about this item

What does the 1000:1 attenuation rate mean for the maximum input voltage my oscilloscope sees?

The 1000:1 attenuation divides the input by 1000, so a 28 kV DC signal becomes 28 V at the BNC connector, keeping the oscilloscope within its safe input range.

What are the probe's physical dimensions and weight, and will it fit my bench setup?

The probe measures 80 mm by 80 mm by 320 mm and weighs 460 g, making it compact enough for most bench or field use.

How do I connect and compensate the P6028A, and what step is commonly missed?

Connect the BNC to the oscilloscope's 1 MΩ input, attach the ground lead securely, then adjust the compensation trimmer for a square 1 kHz calibrator signal; the step often missed is verifying compensation at the probe's 75 MHz bandwidth limit.
