Perle S-1110P-S2Sc10Xt media converter mount, compact metal bracket with mounting holes

Perle

Perle S-1110P-S2Sc10Xt Media Converter Mount

SKU CH-RS1Y-DYWJA

A media converter mount supporting 10/100/1000Base-T to 1000BASE-LX single-mode fibre up to 10 km with PoE power sourcing and extended temperature operation

  • TypeData & Communication
  • SizeMaximum frame size of 10,240 bytes -- Gigabit; Maximum frame
  • Industrial temperature range suits harsh environments
  • PoE power sourcing delivers power over Ethernet cable
  • Converts 10/100/1000BASE-T to 1000BASE-LX/LH single-mode fibre
  • SC connector supports 10 km single-mode or 550 m multimode reach
  • Terminal block connector accepts external power source

Industrial Media Converter Mount

The Perle S-1110P-S2Sc10Xt is a mounting accessory for an industrial-grade media and rate converter. It supports deployment of a PoE power sourcing device that bridges copper and fibre networks in harsh environments. The unit operates across extended temperature ranges for reliable outdoor or factory-floor use. This mount secures the converter for stable, long-term installation.

Distance and Frame Constraints

The converter handles 10/100/1000BASE-T over RJ-45 up to 100 m or 328 ft. Single-mode fibre reaches 10 km or 6.2 miles at 1310 nm, while multimode covers 550 m or 1804 ft with a mode conditioning adapter. Maximum frame size is 10,240 bytes for Gigabit and 2,048 bytes for Fast Ethernet. These fixed limits define the practical reach and packet capacity of the link.

Terminal Block Power Input

The converter requires an external power source connected via a terminal block connector. This industrial power interface replaces a standard AC inlet for direct DC wiring in cabinets or enclosures. Buyers without access to terminal block wiring or an external DC supply cannot power the device. Verify your infrastructure provides this specific connection type before purchase.

Highlights

  • Industrial temperature range suits harsh environments
  • PoE power sourcing delivers power over Ethernet cable
  • Converts 10/100/1000BASE-T to 1000BASE-LX/LH single-mode fibre
  • SC connector supports 10 km single-mode or 550 m multimode reach
  • Terminal block connector accepts external power source

Specifications

BrandPERLE SYSTEMS
TypeData & Communication
SizeMaximum frame size of 10,240 bytes -- Gigabit; Maximum frame size of 2048 bytes -- Fast Ethernet

Questions about this item

Which Perle media converter mount should I pick for an industrial 10/100/1000Base-T link with PoE?

The S-1110P-S2Sc10Xt model supports 10/100/1000BASE-T RJ-45 up to 100 m and 1000BASE-LX/LH 1310 nm single-mode SC up to 10 km, with PoE power sourcing and extended temperature operation.

What does the 10 km single-mode reach mean when the converter is installed in a rack?

It means the fibre link can span up to 10 km or 6.2 miles between this converter and the far-end device, provided you use single-mode SC patch cords and stay within the 1310 nm wavelength budget.

How does the RJ-45 100 m limit affect a Gigabit connection in practice?

At Gigabit speed the copper segment is capped at 100 m or 328 ft, and the maximum frame size allowed is 10,240 bytes, so plan cable runs and MTU settings accordingly.
