Perle C-110-S2LC40 media converter mount, compact metal enclosure, matte finish

Perle

Perle C-110-S2LC40 Media Converter Mount

SKU CH-BHC4-AYXR3

Mounts a 10/100Base-TX to 100Base-EX single-mode LC media converter supporting 40 km links

  • TypeData & Communication
  • SizeMaximum frame size of 2048 bytes
  • Converts 10/100Base-TX copper to 100Base-EX single-mode fibre
  • Extends network reach up to 40 km over single-mode fibre
  • Uses LC connector at 1310 nm wavelength for reliable link
  • Supports maximum frame size of 2048 bytes for efficient data handling
  • Provides 100 m copper distance with RJ-45 interface

Perle 10/100 Media Converter Mount

The Perle C-110-S2LC40 is a media and rate converter module designed for network infrastructure. It bridges copper and fibre segments in enterprise or campus environments. Installers use it to extend Ethernet reach beyond standard twisted-pair limits.

100Base-EX single-mode reach 40 km

The module converts 10/100Base-TX signals at 100 m over RJ-45 to 100Base-EX 1310 nm single-mode fibre up to 40 km. Maximum frame size is 2048 bytes, so jumbo frames beyond that length are not supported. Bandwidth tops out at 100 Mbps full duplex.

LC connector single-mode fibre mount

An LC duplex receptacle accepts standard single-mode patch cords for the 40 km link. The RJ-45 port handles the copper side with auto-negotiation for 10 or 100 Mbps. No PoE pass-through or management features are included.

Highlights

  • Converts 10/100Base-TX copper to 100Base-EX single-mode fibre
  • Extends network reach up to 40 km over single-mode fibre
  • Uses LC connector at 1310 nm wavelength for reliable link
  • Supports maximum frame size of 2048 bytes for efficient data handling
  • Provides 100 m copper distance with RJ-45 interface

Specifications

BrandPERLE SYSTEMS
TypeData & Communication
SizeMaximum frame size of 2048 bytes

Questions about this item

Will the C-110-S2LC40 mount work with my existing 10/100Base-TX network switches?

The module provides a 10/100Base-TX RJ-45 port supporting up to 100 m or 328 ft, so it connects directly to older 10/100 switches without configuration changes.

How can I verify the 100Base-EX link is operating correctly after installation?

Check that the link light is solid on both the RJ-45 and LC ports; the converter handles frames up to 2048 bytes across the 40 km single-mode fibre at 1310 nm.

Does the package include the LC single-mode patch cables needed for the 40 km fibre run?

The converter module itself is supplied; LC single-mode patch cables for the 1310 nm 40 km link must be purchased separately.
