Perle media converter module in compact rectangular form with SC fiber ports

Perle

Perle C-1000Mm-S1Sc10D Media Converter Mount

SKU CH-875V-CRBBE

Mounts a gigabit fiber-to-fiber media converter module converting 1000BASE-SX 850 nm multimode up to 550 m to 1000BASE-BX 1490/1310 nm single-mode up to 10 km

  • TypeData & Communication
  • Gigabit fibre conversion links multimode and single-mode networks
  • 550 m multimode reach at 850 nm wavelength
  • 10 km single-mode reach at 1310/1490 nm wavelengths
  • SC connectors on both fibre interfaces
  • Perle Systems 05061350 module for reliable media conversion

Purpose-built media converter module

The Perle C-1000Mm-S1Sc10D converts Gigabit Ethernet signals between multimode and single-mode fibre. It suits network engineers extending campus or metro links where cable plant types differ. The module fits compatible Perle chassis for managed deployment.

Distance and wavelength constraints

Multimode 1000BASE-SX at 850 nm reaches 550 m or 1804 ft over standard SC duplex fibre. Single-mode 1000BASE-BX uses 1490 nm TX and 1310 nm RX wavelengths on a single SC strand to span 10 km or 6.2 miles. Budget and attenuation must match these fixed limits.

Replaces separate transceivers and patch cords

This single module eliminates the need for two discrete SFPs and an intermediate patch panel when bridging multimode and single-mode segments. The upgrade is worthwhile when rack space, power ports or management simplicity outweigh the cost of a dedicated converter.

Highlights

  • Gigabit fibre conversion links multimode and single-mode networks
  • 550 m multimode reach at 850 nm wavelength
  • 10 km single-mode reach at 1310/1490 nm wavelengths
  • SC connectors on both fibre interfaces
  • Perle Systems 05061350 module for reliable media conversion

Specifications

BrandPERLE SYSTEMS
TypeData & Communication

Questions about this item

Which wavelength combination should I choose for my fibre link?

This module converts 1000BASE-SX at 850 nm multimode to 1000BASE-BX with 1490 nm TX and 1310 nm RX on a single strand.

What distance does the 1000BASE-SX side cover once installed?

The multimode side reaches 550 m or 1804 ft over 850 nm fibre.

What connector standard does the SC interface use and what distance does it cap?

SC connectors on both sides; the single-mode BX side is rated for 10 km or 6.2 miles.
