Compact rectangular programmer unit with silver finish and 40-pin ZIF socket

Peak Design

Peak Design T48 Programmer 8 Adapters USB EPROM Flash BIOS chip Socket nand mcu AVR IC Programmer

SKU CH-VYPV-HRH3K

Programs EPROM, Flash, BIOS, NAND, MCU and AVR chips via USB with a 32-bit 120 MHz MCU, 56-channel high-voltage I/O and 40-pin ZIF socket

  • Programs high-capacity NAND and eMMC up to 256 GB
  • 32-bit MCU at 120 MHz with 4-layer PCB for faster code execution
  • 56-channel high-speed I/O with 64-level adjustable VCC 1.8–6.5 V and VPP to 25 V
  • 40-pin industrial ZIF socket, USB 2.0 HS 480 MHz, no external power needed
  • Runs on Windows XP through Windows 11 with multi-language interface

Professional IC Programmer

The Peak Design T48 programmer is built for developers and maintenance engineers who need to program EPROM, Flash, BIOS, NAND, MCU and AVR chips. It replaces the TL866II Plus with a 32-bit MCU at 120 MHz and a 4-layer PCB, delivering faster programming speeds for high-capacity NAND eMMC up to 256 GB. Eight adapters and a 40-pin industrial ZIF socket cover a wide range of packages, and up to four units can run simultaneously on one PC for small-batch production.

Thermals Noise Power

The unit draws under 500 mA at 5 V from the USB 2.0 high-speed port with no external power supply required, and static consumption sits at 60 mA. Sixteen-channel ISP and 56 dedicated high-voltage insulated I/O channels handle VCC from 1.8 V to 6.5 V and VPP up to 25 V across 64 adjustable levels each. The compact 10 x 6.5 x 2.8 cm enclosure runs cool and silent during extended programming sessions.

Chip Support List

Before purchasing, verify that your exact chip model appears in the manufacturer's support list at www.autoelectric.cn/MiniPro/T48_List.txt. The programmer supports Windows XP through Windows 11 with automatic OS detection and a multi-language interface, but it cannot program devices absent from that list.

Highlights

  • Programs high-capacity NAND and eMMC up to 256 GB
  • 32-bit MCU at 120 MHz with 4-layer PCB for faster code execution
  • 56-channel high-speed I/O with 64-level adjustable VCC 1.8–6.5 V and VPP to 25 V
  • 40-pin industrial ZIF socket, USB 2.0 HS 480 MHz, no external power needed
  • Runs on Windows XP through Windows 11 with multi-language interface

Specifications

No published specifications for this item yet.

Questions about this item

How is the T48 programmer installed, and what step do people often get wrong?

Connect the T48 to a USB 2.0 port on a Windows XP through Windows 11 system; the installer auto-detects the OS, but users sometimes forget to seat the 40-pin ZIF socket firmly before locking the lever, causing intermittent contact.

What maintenance or replacement will the T48 programmer need later?

The 40-pin industrial ZIF socket is pluggable and replaceable; over time the spring contacts can wear, so keeping a spare socket on hand lets you swap it without sending the unit for service.

What limit appears first when the T48 programmer runs sustained high-voltage programming?

The VPP rail tops out at 25 V with 64 adjustable levels; extended sessions at maximum voltage hit that ceiling before the 500 mA USB current limit or the 60 mA idle draw become factors.
