PCE-DC 41 digital clamp multimeter, 25 mm jaw opening, grey and yellow housing, backlit display, test leads included

PCE Instruments

PCE-DC 41 Digital Multimeter Current Clamp 25 mm

SKU CH-E69B-XF3PW

Measures AC and DC voltage to 600 V, current to 600 A and resistance to 1000 Ω with a 25 mm clamp and included leads

  • AC Voltage600 V
  • DC Voltage600 V
  • TypeDigital Multimeters
  • FeaturesMeasuring leads included in the package
  • Measures AC/DC voltage to 600 V with 0.1 V resolution
  • Clamp opening 25 mm enables contact-free current measurement up to 600 A
  • Resistance range 1000 Ω with continuity check for circuit testing
  • Peak-hold and data-hold functions freeze readings on backlit 4-digit display
  • Auto power-off conserves battery during mobile use

Clamp Meter for Mobile Electrical Testing

The PCE-DC 41 is a digital clamp multimeter designed for technicians who need contact-free current measurement on conductors up to 25 mm diameter. It measures AC and DC voltage to 600 V, current to 600 A, and resistance to 1000 ohms. Measuring leads are included for conventional probe work.

Practical Limits of the 600 V CAT Interface

Voltage accuracy is ±1% + 2 digits for DC and ±1.2% ±5 digits for AC between 50 and 500 Hz. Peak-hold readings carry wider tolerances of ±1.5% + 8 digits DC and ±1.7% + 10 digits AC. The 4-digit backlit display shows 0.1 V resolution across all ranges. Auto power-off preserves battery life during intermittent use.

Upgrading from Basic Test Leads

This clamp meter replaces separate multimeter and current probe kits when you need one-handed, non-invasive current checks on live cables. The jump is worth it for field service where disconnecting conductors is impractical. It does not suit buyers who require higher voltage categories, greater resistance ranges, or logging functions not listed here.

Highlights

  • Measures AC/DC voltage to 600 V with 0.1 V resolution
  • Clamp opening 25 mm enables contact-free current measurement up to 600 A
  • Resistance range 1000 Ω with continuity check for circuit testing
  • Peak-hold and data-hold functions freeze readings on backlit 4-digit display
  • Auto power-off conserves battery during mobile use

Specifications

BrandPCE Instruments
ModelPCE-DC 41
AC Voltage600 V
DC Voltage600 V
TypeDigital Multimeters
FeaturesMeasuring leads included in the package

Questions about this item

How do I decide between using the clamp jaws or the included test leads on the PCE-DC 41?

Use the 25 mm clamp for contact-free AC current checks up to 600 A without breaking the circuit; switch to the supplied leads when you need to measure DC or AC voltage up to 600 V, resistance up to 1000 Ω, or run a continuity test.

What does the 600 V rating mean when I am measuring a live mains circuit with this meter?

It is the maximum voltage the input can withstand; the meter will display AC or DC voltage up to 600 V with 0.1 V resolution and stated accuracy of ±1.2 % ±5 digits for AC at 50–500 Hz or ±1 % +2 digits for DC.

What measurement tasks are limited by the clamp opening and the current range of this model?

The 25 mm jaw size sets the maximum conductor diameter you can clamp around, while the 600 A AC range caps the highest current you can read directly without an external accessory.
