14 inch black all-in-one industrial panel PC with capacitive touchscreen

partaker

Partaker Z10-I7 8565U-32G1TB all-in-one PC

SKU CH-768G-788KG

14-inch IP65 industrial all-in-one with Core i7-8565U, 32GB DDR4, 1TB SSD and 10-point capacitive touchscreen

  • Form FactorAll-in-One
  • ColorBlack
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i7 8th Gen
  • CPU NameIntel Core i7-8565U
  • GPU/VGA TypeIntel UHD Graphics

CPU Type Intel Core i7 8th Gen

CPU Name Intel Core i7-8565U

GPU Intel UHD Graphics

Memory 32GB DDR4

SSD 1TB

Struck-through versions exist but are not stocked here.

  • IP65 front protection resists dust and water jets
  • 10-point capacitive touchscreen rated for 200 million touches
  • Intel Core i7-8565U quad-core up to 4.6 GHz with 32 GB DDR4-2400
  • Triple storage bays: mSATA, M.2 2280 NVMe/SATA, 2.5" SATA
  • Fanless aluminium chassis operates 0–50 °C with Mini PCIe 4G/WiFi expansion

Industrial All-in-One with i7-8565U

The Partaker Z10 is a 14-inch fanless panel PC built around an Intel Core i7-8565U processor with 32GB of DDR4 memory and a 1TB SSD. It runs Windows 11 Pro and features a 10-point projected capacitive touchscreen protected to IP65 on the front. The aluminum chassis operates silently from 0 to 50°C.

Suits automation and kiosk deployments

This unit fits machine interfaces, SCADA stations and self-service terminals that need rugged front-panel sealing and legacy COM ports. Buyers who need a second independent display output beyond HDMI and VGA, or who require wireless connectivity out of the box, should look at something else.

Embedded mounting with mini-PCIe expansion

Installation uses a 340.3 x 225.3 mm cut-out for embedded mounting, with wall, desktop or cantilever options also possible. The mini-PCIe slot with SIM holder accepts 4G or Wi-Fi modules, but antennas are not included. Adding storage means opening the chassis to reach the mSATA, M.2 2280 and 2.5-inch SATA bays.

Highlights

  • IP65 front protection resists dust and water jets
  • 10-point capacitive touchscreen rated for 200 million touches
  • Intel Core i7-8565U quad-core up to 4.6 GHz with 32 GB DDR4-2400
  • Triple storage bays: mSATA, M.2 2280 NVMe/SATA, 2.5" SATA
  • Fanless aluminium chassis operates 0–50 °C with Mini PCIe 4G/WiFi expansion

Specifications

ModelZ10-I7 8565U-32G1TB
Form FactorAll-in-One
ColorBlack
Operating SystemWindows 11 Pro
CPU TypeIntel Core i7 8th Gen
CPU NameIntel Core i7-8565U
GPU/VGA TypeIntel UHD Graphics
Memory Capacity32GB DDR4
SSD1TB
HDDNo
Screen Size14"
TouchscreenYes

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What power input does the unit require to operate?

The system ships with a 12 V DC adapter that accepts 100-240 V AC at 50-60 Hz, so a standard mains outlet is all that is needed.

Will the two COM ports and VGA output still work with my existing serial and display equipment?

Yes, the rear I/O includes two COM ports and a VGA connector alongside HDMI, dual LAN and four USB ports for legacy peripherals.

How can I confirm the touchscreen and fanless cooling are functioning correctly after installation?

Verify 10-point touch response on the 14-inch 1600×900 panel and check that the aluminium chassis remains silent while the CPU runs up to 4.6 GHz under load.
