Gray 14-inch all-in-one panel PC with IP65 front bezel and projected capacitive touchscreen

partaker

Partaker Z10-I5 6200U-16G256G1TB 14" IP65 Panel PC

SKU CH-Q8D2-R2B0S

A 14-inch IP65 rugged panel PC with 10-point capacitive touch, Intel Core i5-6200U, 16GB DDR4, 256GB SSD and 1TB HDD for continuous industrial use

  • Form FactorAll-in-One
  • ColorGray
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i5 6th Gen
  • CPU NameIntel Core i5-6200U
  • GPU/VGA TypeIntel HD Graphics 520

CPU Type Intel Core i5 6th Gen

CPU Name Intel Core i5-6200U

Memory Capacity 16GB DDR4

SSD 256GB

HDD 1TB

Struck-through versions exist but are not stocked here.

  • IP65 front panel resists dust and water jets in harsh environments
  • 10-point capacitive touch enables precise multi-finger control on 14-inch display
  • Fanless aluminium cooling runs silently with 6th Gen Core i5-6200U processor
  • Dual 256 GB SSD and 1 TB HDD storage with 16 GB DDR4 memory
  • HDMI, VGA, dual LAN, two COM and four USB ports for industrial connectivity

Industrial panel PC for harsh environments

The Partaker Z10-I5 6200U-16G256G1TB is a 14-inch all-in-one panel PC built for continuous operation in demanding industrial settings. It runs Windows 11 Pro on a 6th Gen Intel Core i5-6200U processor with Intel HD Graphics 520. The system includes 16GB DDR4 memory, a 256GB SSD and a 1TB HDD for mixed storage needs.

Fanless aluminum chassis with IP65 front protection

A passive aluminum cooling system enables silent, maintenance-free performance without moving parts. The front panel carries an IP65 rating against dust and water jets, while the projected capacitive touchscreen supports 10-point input. Connectivity covers HDMI, VGA, two USB 3.0, two USB 2.0, dual LAN, two COM ports and audio jacks, plus a Mini PCIe slot with SIM holder for wireless expansion. Embedded mounting brackets are included for panel integration.

Interface and environmental limits

The 1600 x 900 TFT LED display offers 200 cd/m2 brightness, 400:1 contrast and viewing angles of 45 degrees left or right, 15 degrees up and 35 degrees down. Touch durability is rated at 200 million operations with 86 percent light transmittance. Operating temperature spans 0 to 50 Celsius with the SSD or 0 to 40 Celsius with the HDD installed. The unit accepts 100-240V AC input converted to 12V DC and carries CCC EMC certification.

Highlights

  • IP65 front panel resists dust and water jets in harsh environments
  • 10-point capacitive touch enables precise multi-finger control on 14-inch display
  • Fanless aluminium cooling runs silently with 6th Gen Core i5-6200U processor
  • Dual 256 GB SSD and 1 TB HDD storage with 16 GB DDR4 memory
  • HDMI, VGA, dual LAN, two COM and four USB ports for industrial connectivity

Specifications

ModelZ10-I5 6200U-16G256G1TB
Form FactorAll-in-One
ColorGray
Operating SystemWindows 11 Pro
CPU TypeIntel Core i5 6th Gen
CPU NameIntel Core i5-6200U
GPU/VGA TypeIntel HD Graphics 520
Memory Capacity16GB DDR4
SSD256GB
HDD1TB
Screen Size14"
TouchscreenYes

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What resolution does the HDMI output support on this Z10 panel PC?

The HDMI port can drive the panel's native 1600 x 900 resolution for external displays.

What are the panel cut-out dimensions for embedded mounting?

The required opening hole is 340.3 x 225.3 mm for flush panel installation.

How do you install the embedded buckle kits, and what step is often missed?

Insert the buckles into the chassis slots and tighten evenly; the step often missed is verifying the front bezel sits flush to achieve the IP65 seal.
