Silver 1U rack-mount firewall appliance with six RJ-45 ports and four SFP+ cages on the front panel

partaker

Partaker R6-C3958-32G-1TB firewall appliance

SKU CH-01S8-CDC1F

1U rack-mount firewall with Atom C3958, 32 GB DDR4, 1 TB NVME, six 1 GbE and four 10 GbE SFP+ ports

  • Firewall TypeCabinet Type
  • TypeWired
  • LAN Ports6 x RJ-45
  • Wired Speed10/100/1000 Mbps
  • OS SupportRouterOS
  • Hardware AES-NI encryption accelerates firewall throughput on the Atom C3958
  • 1U rack-mountable chassis fits 19-inch cabinets with included brackets
  • Six 1GbE LAN plus four 10G SFP+ ports handle diverse uplink needs
  • 32GB DDR4 RAM and 1TB SSD storage support heavy logging and caching
  • 25W TDP with silent ball-bearing fan enables 24/7 data-centre operation

1U firewall appliance with Atom C3958

The Partaker R6-C3958-32G-1TB is a 1U rack-mountable firewall appliance built around an Intel Atom C3958 processor with AES-NI hardware encryption. It ships with 32 GB of DDR4 memory and a 1 TB NVME SSD, supporting up to 64 GB of RAM. The unit runs open-source platforms such as OPNsense, pfSense, RouterOS, FreeBSD, Linux and Windows for versatile network security deployment.

Six 1GbE and four 10G SFP+ ports

The appliance provides six RJ-45 LAN ports via two Intel I211 and four I350 controllers, plus four SFP+ optical ports using the X553 controller for 10 GbE fiber connectivity. I/O includes Console, USB 2.0, USB 3.0, VGA and an AC power socket. Expansion options cover a Mini PCIE slot, an M.2 3052 slot with SIM support and a PCIe x8 slot for additional cards.

Suited for rack deployments needing 10G uplinks

This unit fits administrators who require a compact 1U chassis with multiple 10 GbE SFP+ uplinks and hardware AES-NI acceleration for VPN and firewall throughput. Buyers who need more than four 10G ports, higher single-thread CPU performance or a larger storage bay count should look at alternative platforms.

Highlights

  • Hardware AES-NI encryption accelerates firewall throughput on the Atom C3958
  • 1U rack-mountable chassis fits 19-inch cabinets with included brackets
  • Six 1GbE LAN plus four 10G SFP+ ports handle diverse uplink needs
  • 32GB DDR4 RAM and 1TB SSD storage support heavy logging and caching
  • 25W TDP with silent ball-bearing fan enables 24/7 data-centre operation

Specifications

ModelR6-C3958-32G-1TB
Firewall TypeCabinet Type
TypeWired
LAN Ports6 x RJ-45
Wired Speed10/100/1000 Mbps
OS SupportRouterOS

Questions about this item

When will the 25 W TDP ball-bearing fan need cleaning or replacement?

The ball-bearing fan is rated for continuous 24/7 operation; plan to clean dust from the intake vents every six to twelve months and replace the fan only if bearing noise develops.

What limits sustained throughput on the 4 x SFP+ X553 10 GbE ports?

The Intel Atom C3958 CPU tops out at 2.0 GHz with 16 MB cache, so encryption-heavy workloads will hit the processor ceiling before the 10 GbE links saturate.

How much heat and noise does the 12 V 6.25 A PSU produce in a 19-inch rack?

The 25 W TDP and turbo-silent ball-bearing fan keep chassis surface temperatures within the 0–50 °C operating range while acoustic output stays low enough for data-centre aisles.
