Silver 1U rackmount firewall appliance with six RJ-45 ports and four SFP+ cages

partaker

Partaker R6-C3808-32G-512G firewall appliance

SKU CH-JSAD-00JAM

1U rack firewall appliance with Intel Atom C3808, 6×GbE, 4×10G SFP+, 32 GB DDR4 and 512 GB SSD

  • Firewall TypeCabinet Type
  • TypeWired
  • LAN Ports6 x RJ-45
  • Wired Speed10/100/1000 Mbps
  • OS SupportRouterOS
  • 12M cache Atom C3808 with AES-NI accelerates encrypted throughput
  • 32 GB DDR4 and 512 GB NVME SSD ready for heavy logging
  • Six 1 GbE plus four 10 GbE SFP+ ports handle diverse uplinks
  • 1U 484 x 252 x 48 mm chassis fits standard 19 inch racks
  • 25 W TDP and ball-bearing fan enable silent 24/7 operation

1U firewall appliance for high-throughput networks

The Partaker R6-C3808-32G-512G packs an Intel Atom C3808 processor with AES-NI acceleration, 32 GB of DDR4 RAM and a 512 GB NVME SSD into a 1U rack-mount chassis. It targets network engineers and MSPs who need a ready-to-deploy platform for OPNsense, pfSense or RouterOS in data-centre or branch-office racks.

Connectivity and physical integration

Six RJ-45 ports backed by Intel I211 and I350 controllers deliver 1 GbE wired links, while four SFP+ cages driven by an X553 controller provide 10 GbE fibre uplinks. Console, USB 2.0, USB 3.0 and VGA ports sit on the front for local management, and the 484 x 252 x 48 mm enclosure includes rack ears, wall-mount brackets and rubber feet for flexible mounting.

Upgrade path and fit

The appliance replaces older 1 GbE-only boxes when 10 GbE fibre uplinks become necessary, and the C3808’s AES-NI offload makes the jump worthwhile for VPN-heavy workloads. It is not for buyers who need more than 64 GB of RAM, additional PCIe x8 cards beyond the single slot, or PoE switching built into the same unit.

Highlights

  • 12M cache Atom C3808 with AES-NI accelerates encrypted throughput
  • 32 GB DDR4 and 512 GB NVME SSD ready for heavy logging
  • Six 1 GbE plus four 10 GbE SFP+ ports handle diverse uplinks
  • 1U 484 x 252 x 48 mm chassis fits standard 19 inch racks
  • 25 W TDP and ball-bearing fan enable silent 24/7 operation

Specifications

ModelR6-C3808-32G-512G
Firewall TypeCabinet Type
TypeWired
LAN Ports6 x RJ-45
Wired Speed10/100/1000 Mbps
OS SupportRouterOS

Questions about this item

How fast do the SFP+ X553 ports actually run?

The four SFP+ ports use the Intel X553 controller and operate at 10 Gbps each.

What rack depth does the 1U chassis require?

The unit is 484 mm wide, 252 mm deep and 48 mm high, fitting a standard 19-inch rack with the included mounting ears.

How do I load my own firewall image, and what boot mode must I select?

Insert a USB stick, enter UEFI BIOS, disable Secure Boot, set the USB as first boot device, then install pfSense or OPNsense.
