Silver 1U rack-mount appliance, six RJ-45 ports, four SFP+ cages, front panel console and USB, mounting ears attached

partaker

Partaker R6-C3808-16G-512G firewall appliance

SKU CH-A5W4-W2JK2

1U rack firewall with Atom C3808, 16 GB DDR4, 512 GB SSD, six 1 GbE RJ-45 and four 10 GbE SFP+ ports

  • Firewall TypeCabinet Type
  • TypeWired
  • LAN Ports6 x RJ-45
  • Wired Speed10/100/1000 Mbps
  • OS SupportRouterOS
  • AES-NI encryption offloads CPU during high-speed VPN traffic
  • Intel Atom C3808 reaches 2.0 GHz for responsive firewall throughput
  • Six 1GbE RJ-45 plus four 10G SFP+ ports handle diverse uplinks
  • 1U 19-inch rack chassis fits standard cabinets at 484 x 252 x 48mm
  • 16GB DDR4 and 512GB NVME SSD ship pre-installed for immediate deployment

Purpose-built firewall appliance

The Partaker R6-C3808-16G-512G is a 1U rack-mountable firewall appliance built around an Intel Atom C3808 processor with AES-NI hardware encryption. It ships with 16G DDR4 memory and a 512G NVME SSD, ready for immediate deployment with platforms such as OPNsense or pfSense. The unit targets network administrators who need a compact, low-power security gateway for branch offices or data-centre racks.

Capacity and headroom

Six RJ-45 ports deliver 1GbE connectivity while four SFP+ ports based on the X553 controller provide 10GbE fiber uplinks. The C3808 runs at up to 2.0 GHz with a 25W TDP, cooled by a silent ball-bearing fan for continuous operation. Memory can be expanded to 64G across two SODIMM slots, and an additional 2.5-inch SATA drive plus Mini PCIE and M.2 3052 slots allow storage or wireless expansion.

Upgrade path

The appliance replaces older 1U boxes that lack 10GbE SFP+ density or AES-NI acceleration, and it supersedes software-only virtual firewalls that cannot guarantee line-rate packet processing. The jump is worthwhile when a deployment demands hardware-accelerated encryption, mixed copper and fiber interfaces, and a fan-cooled chassis rated for 24/7 duty in a 19-inch rack.

Highlights

  • AES-NI encryption offloads CPU during high-speed VPN traffic
  • Intel Atom C3808 reaches 2.0 GHz for responsive firewall throughput
  • Six 1GbE RJ-45 plus four 10G SFP+ ports handle diverse uplinks
  • 1U 19-inch rack chassis fits standard cabinets at 484 x 252 x 48mm
  • 16GB DDR4 and 512GB NVME SSD ship pre-installed for immediate deployment

Specifications

ModelR6-C3808-16G-512G
Firewall TypeCabinet Type
TypeWired
LAN Ports6 x RJ-45
Wired Speed10/100/1000 Mbps
OS SupportRouterOS

Questions about this item

Will the six 1GbE RJ-45 ports and four 10GbE SFP+ ports connect directly to my existing Cat5e patch panel and 10G DAC cables?

Yes, the six RJ-45 ports run at 10/100/1000 Mbps over Cat5e, and the four SFP+ cages accept standard 10G direct-attach or optical modules.

Which front-panel LEDs or console messages confirm the Atom C3808, 16GB DDR4, and 512GB NVMe are all detected at boot?

The VGA console shows the BIOS POST listing CPU C3808, two DDR4 SODIMMs totalling 16GB, and the M.2 2280 NVMe drive before the OS loader starts.

Does the shipment include rack-mount ears, a power cord, and any pre-installed OS, or must I source them separately?

The box contains the appliance, rack-mount ears, and a power cord; an OS is not pre-installed, so you will load pfSense, OPNsense, or another platform yourself.
