Silver 1U rackmount box, 19 inch front with ten RJ45 ports four SFP+ cages VGA USB power switch

partaker

Partaker R13 firewall appliance C3958 8G RAM 256G SSD

SKU CH-STW5-80HPB

A 1U rack-mount firewall appliance with an Intel Atom C3958 processor, 8 GB DDR4 RAM, 256 GB NVME storage, ten RJ-45 LAN ports and four SFP+ interfaces

  • Firewall TypeCabinet Type
  • TypeWired
  • LAN Ports10 x RJ-45
  • Wired Speed10/100/1000 Mbps
  • OS SupportRouterOS
  • Intel Atom C3958 with AES-NI accelerates VPN and encryption workloads
  • Ten Gigabit LAN ports plus four SFP+ uplinks handle diverse WAN and LAN links
  • 8 GB DDR4 memory and 256 GB NVME SSD deliver responsive firewall and logging performance
  • 1U rack-mount chassis with silent ball-bearing fan fits standard 19-inch cabinets
  • UEFI-only boot and multi-OS support simplify deployment of OPNsense, pfSense or RouterOS

Partaker R13 1U firewall appliance

The Partaker R13 is a 1U rack-mount firewall appliance built around an Intel Atom C3958 processor with eight cores and AES-NI acceleration. It ships with 8 GB of DDR4 memory and a 256 GB NVME SSD, ready for OPNsense, pfSense, RouterOS or other FreeBSD and Linux based network operating systems.

Check power, rack space and expansion needs

Verify that your rack or shelf can accommodate a 19 inch 1U chassis measuring 484 by 252 by 48 mm and weighing 3.2 kg. The unit requires a 100 to 240 V AC supply rated at 1.0 A, with an internal 12 V 6.25 A output. Confirm whether you need the mini PCIe or M.2 3052 slots for additional Wi-Fi or 4G modules with a SIM card.

Ten copper ports, four SFP+ cages and room to grow

The appliance provides ten RJ-45 ports, including two I211 and four I350 at 1 GbE plus four I225-V at 2.5 GbE, alongside four SFP+ cages using the X553 controller. A PCIe x8 slot is available for further expansion. Two SODIMM slots support up to 64 GB of DDR4, while an additional M.2 2280 NVME and a 2.5 inch SATA bay allow extra storage.

Highlights

  • Intel Atom C3958 with AES-NI accelerates VPN and encryption workloads
  • Ten Gigabit LAN ports plus four SFP+ uplinks handle diverse WAN and LAN links
  • 8 GB DDR4 memory and 256 GB NVME SSD deliver responsive firewall and logging performance
  • 1U rack-mount chassis with silent ball-bearing fan fits standard 19-inch cabinets
  • UEFI-only boot and multi-OS support simplify deployment of OPNsense, pfSense or RouterOS

Specifications

ModelR13-C3958-8G-256G
Firewall TypeCabinet Type
TypeWired
LAN Ports10 x RJ-45
Wired Speed10/100/1000 Mbps
OS SupportRouterOS

Questions about this item

What comes in the box and do I need to buy a console cable or SFP+ modules separately?

The package includes the R13 appliance, rack ears, a power cord and a warranty card. A console cable and SFP+ transceivers are not included and must be purchased separately.

Should I choose the 8 GB RAM and 256 GB SSD model or plan to upgrade to the 64 GB maximum?

The unit ships with 8 GB in two SODIMM DDR4 2400 MT/s slots and a 256 GB M.2 2280 NVME PCIE 3.0 x2 SSD. It supports up to 64 GB RAM and has an additional 2.5-inch SATA bay for extra storage.

How does the Atom C3958 2.0 GHz CPU with AES-NI perform when running OPNsense with a full 10 GbE load?

The 16-core C3958 at 2.0 GHz includes AES-NI acceleration, enabling efficient VPN and firewall throughput on OPNsense or pfSense while the four X553 SFP+ ports handle 10 GbE traffic.
