Silver 1U rackmount firewall appliance with front ports and mounting ears

partaker

partaker R13-C3958-32G-1TB firewall appliance

SKU CH-94H0-SET9Z

1U rack-mount firewall appliance with Intel Atom C3958 processor, 32 GB DDR4 RAM, 1 TB storage, ten 1 GbE and four 2.5 GbE RJ-45 ports plus four SFP+ X553 interfaces

  • Firewall TypeCabinet Type
  • TypeWired
  • LAN Ports10 x RJ-45
  • Wired Speed10/100/1000 Mbps
  • OS SupportRouterOS
  • Intel Atom C3958 with AES-NI for accelerated VPN throughput
  • 10 RJ-45 ports plus 4 SFP+ uplinks for flexible WAN/LAN design
  • 32 GB DDR4 and 1 TB NVME storage ready for logging and caching
  • 1U 19-inch rackmount chassis with silent ball-bearing fan for quiet operation
  • 25 W TDP and 100-240 V input for efficient always-on deployment

Purpose-built firewall appliance

The Partaker R13-C3958-32G-1TB is a 1U rack-mount network security device built around an Intel Atom C3958 processor with 16M cache and up to 2.0 GHz. It ships with 32 GB of DDR4 memory and a 1 TB NVME SSD, ready for OPNsense, pfSense, RouterOS or other open-source firewall distributions. The platform targets administrators who need a dedicated gateway with hardware AES-NI acceleration.

Connectivity and build

The chassis measures 484 x 252 x 48 mm and includes rack ears, wall-mount brackets and rubber feet for flexible placement. Ten RJ-45 ports provide six 1GbE and four 2.5GbE links, while four SFP+ cages use the X553 controller for fibre uplinks. Front-panel I/O adds console, USB 2.0, USB 3.0 and VGA; internal expansion offers Mini PCIE, M.2 3052 with SIM slot and a PCIe x8 slot. A 25 W TDP is cooled by a single ball-bearing fan.

Pre-purchase checks

Verify that your rack or shelf accommodates a 19-inch 1U form factor and that the 100-240 V AC input matches local power infrastructure. Confirm the SFP+ modules you plan to use are compatible with the X553 controller. Ensure the single PCIe x8 slot satisfies any additional card requirements, as no further expansion bays are present. The 32 GB RAM ceiling is 64 GB if future growth is anticipated.

Highlights

  • Intel Atom C3958 with AES-NI for accelerated VPN throughput
  • 10 RJ-45 ports plus 4 SFP+ uplinks for flexible WAN/LAN design
  • 32 GB DDR4 and 1 TB NVME storage ready for logging and caching
  • 1U 19-inch rackmount chassis with silent ball-bearing fan for quiet operation
  • 25 W TDP and 100-240 V input for efficient always-on deployment

Specifications

ModelR13-C3958-32G-1TB
Firewall TypeCabinet Type
TypeWired
LAN Ports10 x RJ-45
Wired Speed10/100/1000 Mbps
OS SupportRouterOS

Questions about this item

What speed do the four SFP+ X553 ports actually cap at?

The four SFP+ ports use the Intel X553 controller and each lane runs at up to 10 Gbps, so the practical ceiling is 10 Gbps per port.

What rack depth and clearance does the 1U 19-inch chassis need?

The unit is 484 mm wide, 252 mm deep and 48 mm high; it fits a standard 19-inch rack with the included mounting ears and requires front-to-rear airflow space.

How is OPNsense installed on the M.2 NVMe drive, and what BIOS step is often missed?

Boot the UEFI-only firmware from a USB 3.0 stick, select the M.2 2280 NVMe target, and ensure Secure Boot is disabled or the OPNsense keys are enrolled before the first reboot.
