Silver 1U rackmount firewall appliance with front panel ports and mounting ears

partaker

Partaker R13-C3808-32G-512G firewall appliance

SKU CH-AV1R-1HYAQ

A 1U rack-mount firewall appliance with a 12-core Atom C3808 processor, 32 GB DDR4 memory, 512 GB NVME storage, ten RJ-45 ports up to 2.5 GbE and four SFP+ links

  • Firewall TypeCabinet Type
  • TypeWired
  • LAN Ports10 x RJ-45
  • Wired Speed10/100/1000 Mbps
  • OS SupportRouterOS
  • Atom C3808 CPU with AES-NI accelerates encrypted VPN throughput
  • 32 GB DDR4 and 512 GB NVME SSD handle large state tables and logs
  • Ten RJ-45 ports plus four SFP+ uplinks give flexible WAN/LAN segmentation
  • 1U 19-inch rackmount chassis with silent fan suits space-constrained server rooms
  • Supports OPNsense, pfSense and RouterOS for immediate open-source firewall deployment

Purpose-built 1U firewall appliance

The Partaker R13-C3808-32G-512G is a 1U rack-mountable firewall appliance built around an Intel Atom C3808 processor with twelve megabytes of cache and a maximum turbo frequency of 2.0 GHz. It ships with 32 GB of DDR4 memory and a 512 GB NVME SSD, and supports operating systems such as RouterOS, pfSense and OPNsense. The platform targets network administrators who need a dedicated security gateway with ten RJ-45 ports and four SFP+ optical interfaces.

25 W TDP with silent ball-bearing fan

The system operates at a thermal design power of 25 W, drawing 1.0 A at 100-240 V AC or 6.25 A at 12 V DC. A dedicated ball-bearing cooling fan keeps the processor stable across an operating range of 0 to 50 °C for commercial drives or -20 to 50 °C for industrial SSDs, with ambient humidity tolerance of 5 to 90 percent non-condensing. Low heat output and quiet airflow suit continuous deployment in rack cabinets or wall-mounted locations.

Ten copper ports plus four SFP+ and expansion slots

The chassis provides ten LAN ports — two Intel I211 1GbE, four I350 1GbE and four I225-V 2.5GbE — alongside four SFP+ optical ports based on the X553 controller. I/O includes console, USB 2.0, USB 3.0 and VGA. Internal expansion offers one Mini PCIE slot, one M.2 3052 slot with SIM support and one PCIe x8 slot for additional connectivity. The 19-inch rackable enclosure measures 484 x 252 x 48 mm and includes mounting ears, wall-hanging brackets and foot pads.

Highlights

  • Atom C3808 CPU with AES-NI accelerates encrypted VPN throughput
  • 32 GB DDR4 and 512 GB NVME SSD handle large state tables and logs
  • Ten RJ-45 ports plus four SFP+ uplinks give flexible WAN/LAN segmentation
  • 1U 19-inch rackmount chassis with silent fan suits space-constrained server rooms
  • Supports OPNsense, pfSense and RouterOS for immediate open-source firewall deployment

Specifications

ModelR13-C3808-32G-512G
Firewall TypeCabinet Type
TypeWired
LAN Ports10 x RJ-45
Wired Speed10/100/1000 Mbps
OS SupportRouterOS

Questions about this item

How do I mount the 1U 19 inch cabinet in a rack, and what step is often missed?

Attach the included rackable ears to the chassis sides, slide the unit into the 19 inch rack, and secure it with screws; the step often missed is also fitting the foot pads if the rack rails do not fully support the 484 x 252 mm depth.

Which storage drives may need replacement first, and what are their exact interfaces?

The M.2 2280 NVME PCIE 3.0 x2 SSD and the 2.5 inch SATA SSD or HDD are the two field-replaceable drives; both use standard connectors so either can be swapped without proprietary parts.

What thermal limit appears first when the Atom C3808 runs sustained loads in a 50 °C ambient?

The 25 W TDP combined with the ball silent cooling fan and surface air flow design means the chassis surface temperature reaches its rated maximum before the CPU throttles, so sustained throughput is limited by the 50 °C operating ceiling.
