Silver 1U rackmount firewall appliance with ten RJ45 ports and four SFP+ cages on the front panel

partaker

Partaker R13-C3808-32G-1TB firewall appliance

SKU CH-3MYP-QPXDV

1U rack-mount firewall with Intel Atom C3808, 32 GB DDR4, 1 TB NVME SSD, ten RJ-45 ports and four SFP+ uplinks

  • Firewall TypeCabinet Type
  • TypeWired
  • LAN Ports10 x RJ-45
  • Wired Speed10/100/1000 Mbps
  • OS SupportRouterOS
  • Intel Atom C3808 with AES-NI accelerates encrypted traffic
  • 32 GB DDR4 and 1 TB NVME storage handle heavy logging
  • Ten RJ-45 ports plus four SFP+ give flexible uplink options
  • 1U 19-inch rackmount chassis fits standard cabinets
  • 25 W TDP and silent fan keep heat and noise low

Purpose-built firewall appliance

The Partaker R13-C3808-32G-1TB is a 1U rack-mount network security device powered by an Intel Atom C3808 processor running at 2.0 GHz with AES-NI acceleration. It ships with 32 GB of DDR4 memory and a 1 TB NVME SSD, ready for OPNsense, pfSense or other open-source firewall distributions. The platform targets small-to-mid-size organisations that need a dedicated, low-power gateway for routing, VPN and intrusion-prevention workloads.

Throughput headroom and I/O limits

Ten RJ-45 ports deliver six 1 GbE and four 2.5 GbE links, while four SFP+ cages wired to an X553 controller add 10 GbE fibre uplinks. The Atom C3808’s eight cores and 25 W TDP handle stateful inspection and IPsec encryption at line rate on the 1 GbE interfaces, but sustained 10 GbE throughput with deep-packet inspection will saturate the CPU. Memory caps at 64 GB, so large connection tables or heavy logging may require an upgrade from the factory 32 GB.

Rack integration and expansion

The 19-inch chassis measures 484 x 252 x 48 mm and includes mounting ears, wall brackets and rubber feet for flexible placement. A single ball-bearing fan keeps the 25 W thermal envelope quiet in a server cabinet. One PCIe x8 slot, a Mini PCIe socket and an M.2 3052 slot with SIM tray allow 4G or Wi-Fi add-ons, while a second 2.5-inch SATA bay provides local log or cache storage. Dual USB ports and a VGA console port complete out-of-band management access.

Highlights

  • Intel Atom C3808 with AES-NI accelerates encrypted traffic
  • 32 GB DDR4 and 1 TB NVME storage handle heavy logging
  • Ten RJ-45 ports plus four SFP+ give flexible uplink options
  • 1U 19-inch rackmount chassis fits standard cabinets
  • 25 W TDP and silent fan keep heat and noise low

Specifications

ModelR13-C3808-32G-1TB
Firewall TypeCabinet Type
TypeWired
LAN Ports10 x RJ-45
Wired Speed10/100/1000 Mbps
OS SupportRouterOS

Questions about this item

Can the 10 RJ-45 ports at 1GbE and 2.5GbE connect directly to my existing gigabit switches without re-cabling?

Yes, the six 1GbE and four 2.5GbE RJ-45 ports are backward-compatible with 10/100/1000 Mbps switches, so existing Cat5e or Cat6 cables work without changes.

How do I verify the Atom C3808 and 32 GB DDR4 are recognised correctly after first boot?

Enter the BIOS or your chosen OS dashboard — OPNsense, pfSense, RouterOS or Linux — and confirm the CPU shows 8 cores at up to 2.0 GHz and memory reports 32 GB at 2400 MT/s.

Does the package include SFP+ transceivers for the four X553 cages or must I buy them separately?

The box contains the appliance, rack ears, power cord and warranty card only; SFP+ modules for the four X553 ports are not included and must be purchased separately.
