Silver 1U rackmount firewall appliance with front LAN and SFP+ ports

partaker

Partaker R13-C3808-16G-512G firewall appliance

SKU CH-2PWD-HH3KW

1U rack firewall with Intel Atom C3808, 16 GB DDR4, 512 GB NVME, ten 1 GbE and four 2.5 GbE RJ-45 ports plus four SFP+ uplinks

  • Firewall TypeCabinet Type
  • TypeWired
  • LAN Ports10 x RJ-45
  • Wired Speed10/100/1000 Mbps
  • OS SupportRouterOS
  • Atom C3808 2.0 GHz handles heavy traffic
  • 10 RJ-45 ports plus 4 SFP+ uplinks
  • 16 GB DDR4 with 512 GB NVME storage
  • AES-NI acceleration for VPN workloads
  • 1U rack-mount chassis with silent cooling

Purpose-built network gateway

The Partaker R13-C3808-16G-512G is a 1U rack-mount firewall appliance designed for small-to-medium networks that need deterministic throughput and open-source flexibility. It ships with an Intel Atom C3808 processor, 16 GB of DDR4 memory and a 512 GB NVME SSD, ready for OPNsense, pfSense or similar FreeBSD and Linux distributions.

Ten-gigabit-class port density

The single specification that decides fit is the combination of ten RJ-45 ports and four SFP+ cages driven by an Intel X553 controller. Six ports run at 1 GbE via I211 and I350 controllers, while four I225-V ports deliver 2.5 GbE, giving a mixed copper and fibre front end without add-in cards.

Expansion headroom in a shallow chassis

A PCIe x8 slot, a Mini PCIe socket and an M.2 3052 slot with SIM tray allow wireless, cellular or specialised acceleration cards to be added internally. The 25 W TDP and ball-bearing fan keep acoustic output low, while the 484 mm deep chassis fits standard 19 inch racks and leaves rear clearance for cable management.

Highlights

  • Atom C3808 2.0 GHz handles heavy traffic
  • 10 RJ-45 ports plus 4 SFP+ uplinks
  • 16 GB DDR4 with 512 GB NVME storage
  • AES-NI acceleration for VPN workloads
  • 1U rack-mount chassis with silent cooling

Specifications

ModelR13-C3808-16G-512G
Firewall TypeCabinet Type
TypeWired
LAN Ports10 x RJ-45
Wired Speed10/100/1000 Mbps
OS SupportRouterOS

Questions about this item

How does the 2.0 GHz Atom C3808 perform when running OPNsense or pfSense?

The 8-core C3808 with AES-NI handles VPN encryption, packet filtering and routing at line rate on the 10 Gigabit and 2.5 Gigabit ports, leaving headroom for IDS/IPS packages.

What throughput can the four X553 SFP+ ports sustain in practice?

Each SFP+ port is wired to the X553 controller at 10 Gbps, so the four ports share the PCIe 3.0 x2 link to the CPU, capping combined throughput near 16 Gbps.

Will the 1U chassis fit a standard 19 inch rack and what mounting hardware is included?

The 484 mm wide chassis matches 19 inch rack width and ships with rack ears; wall-mount brackets and rubber feet are also supplied for shelf or wall installation.
