Gray fanless aluminium mini PC, compact box shape with Phoenix terminal ports

partaker

Partaker I35 i7-1255U barebone mini PC 16G 512G

SKU CH-D8X3-Y32SJ

Fanless industrial mini PC with a 10-core i7-1255U, 16 GB DDR5, 512 GB NVMe, dual 2.5G LAN, six COM ports and triple 4K display support

  • ColorGray
  • CPU TypeIntel Core i7 12th Gen

I35 CPU I7 1255U 16GB RAM / 512GB SSD

  • 10-core i7-1255U reaches 4.70 GHz for demanding workloads
  • 16 GB DDR5 4800 MHz and 512 GB NVMe SSD ready to run
  • Triple 4K 60 Hz via two HDMI and full-featured Type-C
  • Dual 2.5 GbE LAN plus six COM Phoenix ports for industrial I/O
  • Fanless aluminium chassis operates silently from -20 °C to +60 °C

Industrial Edge Computing Platform

The Partaker I35 is a fanless mini PC built around an Intel Core i7 1255U processor with ten cores and twelve threads reaching 4.70 GHz. It ships with 16 GB of DDR5 4800 MHz memory and a 512 GB NVMe SSD, ready for industrial automation, medical equipment or logistics gateways. The all-aluminium chassis operates silently from -20 °C to +60 °C.

Sustained Thermal Performance

Passive cooling spreads heat across the entire aluminium body, so the CPU maintains its boost clocks during long workloads without throttling or acoustic noise. Dual 2.5G Ethernet controllers from the I226 family keep network throughput steady under continuous data streams. The 12 V Phoenix power input accepts 100-240 V AC via the supplied adapter for stable 24/7 operation.

Installation & Common Pitfalls

Mounting options include VESA, wall brackets and optional DIN-rail clips, all secured with standard screws. Six COM ports use Phoenix terminals — COM1-2 default to RS232, COM3-6 to RS485 — so wiring must match the protocol before power-on. Expansion requires opening the chassis for M.2 2280 NVMe, M.2 2230 wireless, Mini PCIe 4G or 2.5" SATA devices; the Nano-SIM slot sits inside.

Highlights

  • 10-core i7-1255U reaches 4.70 GHz for demanding workloads
  • 16 GB DDR5 4800 MHz and 512 GB NVMe SSD ready to run
  • Triple 4K 60 Hz via two HDMI and full-featured Type-C
  • Dual 2.5 GbE LAN plus six COM Phoenix ports for industrial I/O
  • Fanless aluminium chassis operates silently from -20 °C to +60 °C

Specifications

ColorGray
CPU TypeIntel Core i7 12th Gen

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How does the fanless aluminium chassis keep the i7-1255U cool when it runs continuously at 4.70 GHz?

The all-aluminium body acts as a heatsink across the -20 to +60 °C range, so the 10-core CPU stays within limits without any moving parts or dust intake.

Which display cables and mounts do I need to use the triple 4K outputs on day one?

You need two HDMI cables and one full-featured Type-C cable for 3840 x 2160 @60 Hz on each screen, plus a VESA, wall or DIN-rail bracket for the 186 x 140 x 66 mm chassis.

Can I keep my existing RS-232 and RS-485 sensors on the six Phoenix COM ports without adapters?

Yes, COM1 and COM2 default to RS-232 while COM3-COM6 default to RS-485, so legacy serial devices plug straight into the 6-pin and 12-pin Phoenix terminals.
