partaker A5 15" IP65 Panel PC i7-6500U 16GB DDR3 128GB SSD
IP65-rated 15" industrial panel PC with fanless aluminium cooling, Intel Core i7-6500U, 16GB DDR3L, 128GB SSD and Windows 11 Pro
- Form FactorAll-in-One
- Operating SystemWindows 11 Pro
- CPU TypeIntel Core i7 6th Gen
- GPU/VGA TypeIntel HD Graphics 520
- Memory Capacity16GB DDR3
- HDDNo
- IP65 front panel withstands dust and water jets in harsh environments
- 5-wire resistive touchscreen operates reliably from 0 to 50 °C
- Intel Core i7-6500U up to 3.10 GHz handles continuous industrial workloads
- Windows 11 Pro 64-bit pre-installed for immediate deployment
- Fanless aluminium alloy cooling runs silently with no moving parts
Built for industrial environments
The Partaker A5 is a 15" all-in-one panel PC with an IP65-rated front panel, designed for continuous operation in harsh conditions. Its fanless aluminium alloy chassis runs silently while resisting dust and water ingress. A high-temperature five-wire resistive touchscreen remains responsive across a 0 to 50 °C range. The system ships with Windows 11 Pro pre-installed for immediate deployment.
Replaces older fan-cooled units
This model upgrades installations that previously relied on active cooling and lower IP ratings, eliminating moving parts that fail in dirty or vibration-heavy settings. The jump is worth it when maintenance access is limited and uptime is critical, as the passive design removes a common failure point. Dual LAN and dual COM ports maintain compatibility with legacy automation networks.
Fits embedded or wall-mounted builds
The unit requires a 348 by 272 mm cut-out and a 12 V DC supply, drawing power from an included 100-240 V AC adapter. Two SODIMM slots are populated with 16 GB DDR3L-1600, leaving no free memory slots. Storage expansion is available through one mSATA, one M.2 2280 and one 2.5" SATA bay. A Mini PCIe slot with SIM holder allows optional wireless connectivity.
Highlights
- IP65 front panel withstands dust and water jets in harsh environments
- 5-wire resistive touchscreen operates reliably from 0 to 50 °C
- Intel Core i7-6500U up to 3.10 GHz handles continuous industrial workloads
- Windows 11 Pro 64-bit pre-installed for immediate deployment
- Fanless aluminium alloy cooling runs silently with no moving parts
Specifications
| Model | A5-PA-150TPC-CE5A(I76)-16G128G |
|---|---|
| Form Factor | All-in-One |
| Operating System | Windows 11 Pro |
| CPU Type | Intel Core i7 6th Gen |
| GPU/VGA Type | Intel HD Graphics 520 |
| Memory Capacity | 16GB DDR3 |
| HDD | No |
| Screen Size | 15" |
| Touchscreen | Yes |
Questions about this item
What panel cut-out size does the 15 inch IP65 front panel require?
The embedded mounting cut-out is 348 by 272 millimetres, matching the opening hole specification for the IP65 sealed front bezel.
Which step is often missed when fitting the unit into an enclosure?
Installers frequently forget to seat the supplied mounting buckle kits into the chassis slots before tightening, which is needed to maintain the IP65 seal.
What is the minimum rated lifespan of the backlight and the resistive touch layer?
The LED backlight is rated for at least 30,000 hours and the five-wire resistive touchscreen for 35 million touches.
