Pack of 500 red insulated copper wire ferrules 18 AWG 13/32in

Panduit

Panduit FSD77-8-DSL2 Ferrule 18 AWG 13/32in PK500

SKU CH-SPQP-RWV08

Pack of 500 tin-plated copper ferrules for 18 AWG wire with red polypropylene insulation

  • TypeElectrical Connectors
  • Tin-plated copper barrel resists corrosion for reliable crimps
  • Red polypropylene insulation identifies 18 AWG wire at a glance
  • 13/32 inch insertion length fits standard terminal blocks
  • CSA C 22.2 No. 291-14 and DIN 46228 Part 4 compliance ensures code acceptance
  • Pack of 500 ferrules supports high-volume panel builds

Wire Ferrules for 18 AWG Applications

This pack contains 500 insulated wire ferrules designed for 18 AWG conductors. The tin-plated copper barrels accept a single wire size and are crimped to create a reliable termination. Red polypropylene insulation identifies the gauge at a glance. The parts meet CSA C 22.2 No. 291-14 and DIN 46228 Part 4 standards.

Crimp Termination Limits

Each ferrule handles only 18 AWG wire with an insertion length of 13/32 in. The barrel diameter is 0.12 in and the ferrule diameter is 0.07 in, so the crimp tool must match these dimensions exactly. Maximum operating temperature is 221 Degrees F, which defines the thermal ceiling for the connection. No other wire sizes or termination styles are supported by this part.

Copper Barrel and Polypropylene Insulation

The barrel is solid copper with a tin-plated finish for corrosion resistance, while the insulation sleeve is polypropylene in red. A barrel length of 0.26 in provides the contact area inside a terminal block. The pack quantity of 500 suits panel-build and maintenance workflows where consistent, repeatable crimps are required day to day.

Highlights

  • Tin-plated copper barrel resists corrosion for reliable crimps
  • Red polypropylene insulation identifies 18 AWG wire at a glance
  • 13/32 inch insertion length fits standard terminal blocks
  • CSA C 22.2 No. 291-14 and DIN 46228 Part 4 compliance ensures code acceptance
  • Pack of 500 ferrules supports high-volume panel builds

Specifications

BrandPANDUIT
TypeElectrical Connectors

Questions about this item

Which ferrule length should I pick for an 18 AWG wire?

This model has a 13/32 in insertion length and a 0.26 in barrel length sized for 18 AWG conductors.

What does the 221 °F rating mean when the ferrule is crimped in a panel?

The polypropylene insulation and tin-plated copper barrel are rated to 221 °F maximum operating temperature.

Which standards cover the crimp interface on this ferrule?

It meets CSA C 22.2 No. 291-14 and DIN 46228 Part 4 for crimp termination.
