Amber G9.5 lamp holder with wire leads

OSRAM SYLVANIA

OSRAM SYLVANIA TP-22XL G9.5 lamp holder

SKU CH-98JC-C8T9T

G9.5 lamp holder fits 575 W to 2000 W stage bulbs with UL and CSA certification

  • ColorAmber
  • G9.5 base fits EHC, GLC, EHD and other listed lamps
  • UL Recognised E31557 and CSA Certified LR20904 for safety compliance
  • Accepts AWG 18, 16 or 14 wire leads rated 600 V and 392 °F
  • Amber colour identifies the holder in stage and studio fixtures
  • Strip length 0.38 in speeds installation

Amber G9.5 lamp holder

The OSRAM SYLVANIA TP-22XL is a ceramic lamp holder designed for stage and studio bulbs that use a G9.5 bi-pin base. It accepts wire leads from AWG 18 down to AWG 14 rated for 600 V and 392 °F. The holder carries UL Recognized component mark E31557 and CSA certification LR20904.

G9.5 base limits

This holder only fits lamps with a G9.5 base; it will not accept GX9.5, GY9.5 or any other pin spacing. The terminal strip length is 0.38 in, so wiring must be trimmed accordingly. Buyers who need a different base type or a longer strip length cannot use this part.

600 V 392 °F wire rating

The single specification that decides fit is the wire-lead rating: any UL recognised and CSA certified wire of AWG 18, 16 or 14 with a minimum 600 V and 392 °F rating. If the installation uses wire outside that gauge range or temperature rating, the holder is not suitable.

Highlights

  • G9.5 base fits EHC, GLC, EHD and other listed lamps
  • UL Recognised E31557 and CSA Certified LR20904 for safety compliance
  • Accepts AWG 18, 16 or 14 wire leads rated 600 V and 392 °F
  • Amber colour identifies the holder in stage and studio fixtures
  • Strip length 0.38 in speeds installation

Specifications

BrandOsram Sylvania
ColorAmber

Questions about this item

Which G9.5-base lamps does the TP-22XL holder accept?

It fits EHC/EHB, GLC 575/115/300, EHD, GLD 750/115/300, EHF, GLE 750/115/1500, EHG, 1000/240V/G9.5, FEL, 1000Q/T6/RTP/C, FEP/240, 1000Q/T6/RTPFS, FLK, 1000T6Q/RTP/CR/BULK, FLK PLUS HPR 575/115, 1000T6Q/RTP/X, FLK/X 115V, 1500T6Q/RTP/GS, GLA 575/115/2000 and FRN 2000T7Q lamps.

What does the 0.38 inch strip length mean when I wire the holder?

It tells you to strip each lead back 0.38 inch so the conductor seats fully in the terminal without exposed copper.

What wire gauges and ratings does the UL/CSA listing allow?

Any UL-recognised and CSA-certified wire of AWG 18, 16 or 14 rated at least 600 V and 392 °F.
