Red aluminium and transparent plastic M.2 NGFF SATA enclosure with USB-C cable

Orico

Orico M.2 NGFF SATA B-Key SSD Enclosure USB 3.1 Type-C Red

SKU CH-0FPC-3XMQZ

Holds a single M.2 SATA B-key SSD up to 2 TB and connects via USB 3.1 Type-C at 5 Gbps with UASP and TRIM support

  • ColorRed
  • SizeM.2
  • TypeEnclosure
  • MaterialAluminum / Plastic
  • Internal InterfaceM.2 NGFF B-Key
  • External InterfaceUSB Type C

External Interface USB Type C

Size M.2 NGFF SSD

  • Tool-free sliding cover lets you swap drives in seconds
  • Aluminium alloy shell with transparent PC panel keeps the SSD cool
  • USB 3.1 Type-C interface delivers up to 5 Gbps transfer speed
  • Supports 2230/2242/2260/2280 mm M.2 SATA B-key SSDs up to 2 TB
  • Plug-and-play on Windows, Mac and Linux with no driver or external power needed

Target Drive & Host

This enclosure accepts NGFF SATA B-Key or M+B Key M.2 modules in 2230, 2242, 2260 and 2280 lengths up to 2TB. It connects to Windows, Mac or Linux hosts through a USB 3.1 Type-C port and works without extra drivers or external power.

Thermals & Power

An aluminium-alloy shell with a transparent polycarbonate window acts as a passive heatsink to draw heat from the drive during sustained transfers. The bus-powered design keeps cable clutter low and draws only the current the host port supplies.

Accessories & Extras

A 15cm Type-C to USB 3.0 cable, a screw set and a sliding cover are included so the SSD can be secured and swapped without tools. UASP and TRIM support are enabled by the onboard controller to maintain write performance over time.

Highlights

  • Tool-free sliding cover lets you swap drives in seconds
  • Aluminium alloy shell with transparent PC panel keeps the SSD cool
  • USB 3.1 Type-C interface delivers up to 5 Gbps transfer speed
  • Supports 2230/2242/2260/2280 mm M.2 SATA B-key SSDs up to 2 TB
  • Plug-and-play on Windows, Mac and Linux with no driver or external power needed

Specifications

BrandORICO
ColorRed
SizeM.2
TypeEnclosure
MaterialAluminum / Plastic
Internal InterfaceM.2 NGFF B-Key
External InterfaceUSB Type C
HDD Count SupportedSingle SSD
Number of Bay1 Bay
Maximum Capacity (per Bay)Up to 2TB

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I install an M.2 2280 SATA B-key SSD into the sliding aluminium enclosure?

Slide the cover off, insert the SSD at an angle into the B-key slot, press it flat, secure it with the supplied screw, then slide the cover back until it clicks.

What part will need replacement if the 15 cm Type-C to USB 3.0 cable frays or the JMS580 bridge overheats?

The cable is a standard USB 3.0 Type-C to Type-A lead and can be swapped for any 15 cm equivalent; the bridge is soldered to the PCB so the whole enclosure would need replacing.

At what transfer rate does the enclosure saturate during long sequential transfers?

The JMS580 bridge is rated for 5 Gbps over USB 3.1 Gen 1, so sustained reads and writes level off at that ceiling.
