Silver 2U rackmount network switch with 64 QSFP28 ports and dual power supplies

NVIDIA

NVIDIA MSN4600-CS2RC network switch 64 QSFP28 2U rackmount

SKU CH-1JQM-C5K1B MPN MSN4600-CS2RC

A managed 2U rackmount switch with 64 QSFP28 ports delivering 6.4 Tb/s throughput and running Cumulus Linux on an Intel x86 CPU

  • FormatRackmount
  • Network Management TypeManaged
  • Primary Ports64 x QSFP28
  • Layer3
  • PowerInput Voltage: 1x/2x, 10A/100-127Vac, 50/60Hz, 6A/200-240Vac
  • Dimensions3.46" x 16.85" x 22.3" 88mm (H) x 428mm (W) x 566.4mm (D)
  • 64 QSFP28 ports deliver 6.4 Tb/s throughput
  • Spectrum-3 switch ASIC enables 100GbE line-rate performance
  • Dual AC power supplies with 466W typical draw
  • Intel x86 quad-core CPU runs Cumulus Linux or Onyx
  • 2U form factor at 14.64kg for dense deployments

64-port QSFP28 100GbE switch

The NVIDIA MSN4600-CS2RC is a managed Layer 3 switch built on the Spectrum-3 ASIC. It delivers 6.4 Tb/s throughput across 64 QSFP28 ports in a 2U rackmount chassis. Dual AC power supplies and an Intel x86 CPU running Cumulus Linux provide a complete open Ethernet platform for data-centre fabrics.

Suited for high-density spine and leaf.

This switch fits spine-and-leaf deployments that need 64 ports of 100GbE in a single 2U unit with front-to-back airflow. It is not for buyers who need only a handful of ports, who require PoE for endpoint devices, or who operate outside the 0°C to 40°C operational temperature range.

64 QSFP28 ports at 100GbE line rate

The defining specification is the 64 QSFP28 interfaces operating at 100GbE each, giving 6.4 Tb/s aggregate switching capacity. If the design calls for fewer than 64 high-speed ports or a different form factor, this model will not match the requirement.

Highlights

  • 64 QSFP28 ports deliver 6.4 Tb/s throughput
  • Spectrum-3 switch ASIC enables 100GbE line-rate performance
  • Dual AC power supplies with 466W typical draw
  • Intel x86 quad-core CPU runs Cumulus Linux or Onyx
  • 2U form factor at 14.64kg for dense deployments

Specifications

BrandNVIDIA
SeriesSpectrum SN4000 Series
ModelSN4600-C
Part NumberMSN4600-CS2RC
FormatRackmount
Network Management TypeManaged
Primary Ports64 x QSFP28
Layer3
PowerInput Voltage: 1x/2x, 10A/100-127Vac, 50/60Hz, 6A/200-240Vac,50/60Hz
Global Power Consumption: Typical power with passive cables (ATIS): 466W
Dimensions3.46" x 16.85" x 22.3"
88mm (H) x 428mm (W) x 566.4mm (D)
Weight14.64kg
TemperatureOperational: 0 degree celsius to 40 degrees celsius
Non-Operational: -40 degrees celsius to 70 degrees celsius
HumidityOperational: 10%-85% non-condensing
Non-Operational: 10%-90% non-condensing
FeaturesMAIN DEVICES:
CPU: Intel x86 2.20GHz Quad Core
PCIe: 4x Gen 3.0
Switch: NVIDIA Spectrum-3
Memory: SN4600C: 8GB RAM, 30GB SSD
Throughput: 6.4 Tb/s
DisclaimerREGULATORY:
Safety/EMC: CB, cTUVus, CE, CU, S_Mark, FCC, VCCI, ICES, RCM, BSMI, KCC, CCC
RoHS: RoHS compliant
Shipping weight9.07 kg
Package size800 × 600 × 170 mm

Questions about this item

How much rack depth does the 2U MSN4600-CS2RC require?

The chassis is 566.4 mm deep (22.3 inches), so allow at least that much usable depth plus cable clearance behind the rear panel.

Which rack-mount hardware is included with the switch?

A rail kit is supplied; attach the rails to the rack first, then slide the 14.64 kg unit in and secure the front brackets — skipping the rail step is the common error.

Are the dual AC power supplies hot-swappable for later replacement?

Yes, the two 100–240 Vac modules can be removed and replaced while the switch stays running, so a failed supply does not require downtime.
