Silver rectangular desktop server chassis with DIN rail mounting clips and ventilation slots

NShi

NShi Server Chassis Desktop DRP-480 48V 10A 480W

SKU CH-1EBH-5K9HK

Delivers 48 V at 10 A with passive PFC and convection cooling for DIN-rail mounting

  • Chassis TypeDesktop
  • Passive PFC meets EN61000-3-2 standard for 480W models
  • Free-air convection cooling eliminates fan noise and moving parts
  • Mounts on DIN rail TS-35 with 7.5 or 15 mm profiles
  • 100% full-load burn-in test validates reliability before shipment
  • Three-year warranty period covers manufacturing defects

Industrial DIN-Rail Power Supply

The NShi DRP-480 is a desktop server chassis power unit rated at 48 volts and 10 amps for 480 watts of continuous output. It is built for automation cabinets, industrial control equipment and rack-mounted systems that need a single regulated rail. The unit accepts AC input between 180 and 264 volts only, so the installer must verify local mains voltage before wiring.

Thermals Noise and Power Draw

Cooling relies on free air convection with no internal fan, so the unit runs silently in normal operation. A built-in passive power-factor correction circuit meets EN61000-3-2 limits at the 480 watt rating. Protections against short circuit, overload, over-voltage and over-temperature engage automatically under fault conditions. Each unit passes a 100 percent full-load burn-in test before shipment.

Mounting and Connectors

The chassis clips onto standard TS-35 DIN rail in either 7.5 or 15 millimetre heights, allowing quick installation inside control panels. An LED indicator shows power-on status at a glance. UL508 listing confirms suitability for industrial control equipment applications. The three-year manufacturer warranty covers defects in materials and workmanship under normal use.

Highlights

  • Passive PFC meets EN61000-3-2 standard for 480W models
  • Free-air convection cooling eliminates fan noise and moving parts
  • Mounts on DIN rail TS-35 with 7.5 or 15 mm profiles
  • 100% full-load burn-in test validates reliability before shipment
  • Three-year warranty period covers manufacturing defects

Specifications

Chassis TypeDesktop

Questions about this item

How is the DRP-480 mounted on a DIN rail, and which clip orientation is often missed?

Snap the unit onto a TS-35 rail, either 7.5 mm or 15 mm depth; the spring clip must face downward so gravity keeps it locked.

What maintenance does the convection-cooled 480 W supply need over its service life?

Vacuum dust from the vent slots annually; no fan bearings or filters to replace.

At what input voltage does the DRP-480-48 shut down first during a brown-out?

The AC range is 180–264 VAC; below 180 VAC the unit turns off.
