Nibco, Inc.
Nibco, Inc. 775-LF 2 1/2 in Bronze FNPT Flange bathware
A bronze Class 150 threaded companion flange with FNPT and flange connections for 2 1/2 inch potable water piping, rated to 269 psi and 200 Degrees F, meeting ASME B 16.18, NSF/ANSI 61 and 372.
- ColorTransparent
- TypePipes, Valves & Fittings
- Lead-free bronze meets NSF/ANSI 61 and 372 for safe potable water
- Class 150 flange rated to 269 psi at 200 °F for reliable service
- FNPT to flange transition simplifies 2-1/2 in pipe connections
- Four 3/4 in bolt holes on 7 in OD ensure secure mounting
- Manufactured to ASME B16.18 under ISO 9001 quality system
NIBCO 775-LF 2-1/2 in Bronze Flange
This NIBCO 775-LF is a Class 150 threaded companion flange made from bronze for potable water systems. It connects a 2-1/2 in FNPT pipe to a flanged joint using four bolt holes on a 7 in outside diameter. The fitting meets ASME B16.18, NSF/ANSI 61 and NSF/ANSI 372 standards. It is rated for 269 psi at 200 Degrees F.
Suits installers joining threaded pipe to flanged
This flange suits plumbers and maintenance teams adapting 2-1/2 in FNPT pipework to a bolted flange connection in potable water service. It is not for systems exceeding the 269 psi or 200 Degrees F limits. Buyers needing a different pipe size, a sweat or press connection, or a higher pressure class should look at other fittings.
Class 150 pressure rating at 269 psi
The single specification that decides fit is the Class 150 rating with a 269 psi maximum operating pressure at 200 Degrees F. Verify your system design pressure and temperature against these limits before selecting this bronze flange.
Highlights
- Lead-free bronze meets NSF/ANSI 61 and 372 for safe potable water
- Class 150 flange rated to 269 psi at 200 °F for reliable service
- FNPT to flange transition simplifies 2-1/2 in pipe connections
- Four 3/4 in bolt holes on 7 in OD ensure secure mounting
- Manufactured to ASME B16.18 under ISO 9001 quality system
Specifications
| Brand | NIBCO |
|---|---|
| Color | Transparent |
| Type | Pipes, Valves & Fittings |
Questions about this item
Will the bronze flange need periodic gasket replacement under normal service?
The Class 150 threaded companion flange uses a flat gasket between the 7 in flange face and the mating pipe; bronze does not corrode in potable water, so only the gasket itself wears and should be inspected during routine system shutdowns.
At 269 psi and 200 °F continuous duty, which rating is reached first?
The 200 °F maximum operating temperature is the limiting factor; pressure capacity drops as temperature rises, so sustained exposure near 200 °F will govern design life before the 269 psi ceiling is tested.
How much heat does the fitting radiate when hot water circulates all day?
Bronze conducts heat efficiently, so the 2 1/2 in body and 7 in flange will approach fluid temperature; insulation jackets are typically added to reduce surface heat loss and protect nearby personnel.
