Bronze tee fitting with three connection ends

Nibco, Inc.

Nibco, Inc. 712RLF-343412 trap

SKU CH-J0WJ-KMWPJ MPN 712RLF-343412

Low-lead bronze tee fitting with C x C x FNPT connections rated to 466 psi and NSF/ANSI 61 Annex G

  • TypeDrain Components
  • MaterialHAWA
  • Low-lead bronze meets NSF/ANSI 61 Annex G for safe potable water
  • Rated to 466 psi maximum pressure for reliable system performance
  • Operates from -20 to 200 degrees F across varied conditions
  • C x C x FNPT tee connects 3/4 in tube to 1/2 in pipe
  • Model 712RLF-343412 identifies the exact low-lead cast bronze fitting

Low-lead bronze tee for copper and iron pipe

This cast-bronze tee connects 3/4-inch copper tube on both run ports to a 1/2-inch female pipe thread branch. The low-lead alloy meets NSF/ANSI 61 Annex G for potable-water systems.

Installers joining copper tube to threaded fittings

Suits plumbers who need a sweat-to-thread transition tee rated for 466 psi and temperatures up to 200 degrees F. Not for drain-waste-vent lines, gas piping, or systems that require a full-port ball valve instead of a tee.

NSF/ANSI 61 Annex G certification

This standard confirms the fitting is approved for drinking-water contact, which is the single specification that decides whether the part complies with local plumbing codes for potable supplies.

Highlights

  • Low-lead bronze meets NSF/ANSI 61 Annex G for safe potable water
  • Rated to 466 psi maximum pressure for reliable system performance
  • Operates from -20 to 200 degrees F across varied conditions
  • C x C x FNPT tee connects 3/4 in tube to 1/2 in pipe
  • Model 712RLF-343412 identifies the exact low-lead cast bronze fitting

Specifications

TypeDrain Components
MaterialHAWA
BrandNibco
Model712RLF-343412

Questions about this item

What is included with the 712RLF-343412 tee and what must be purchased separately?

The box contains the low-lead cast bronze tee with C x C x FNPT connections. Copper tubing, flux, solder and thread sealant for the 1/2 in FNPT branch are not included.

How do I decide between the available versions of this fitting?

The 712RLF-343412 is a single configuration: 3/4 in tube size, 1/2 in pipe fitting branch, 7/8 in x 7/8 in x 1/2 in outside diameters, rated to 466 psi and -20 to 200 °F.

What does the 466 psi rating mean when the tee is installed in a plumbing system?

It indicates the maximum continuous working pressure the cast bronze body can withstand at temperatures up to 200 °F, provided joints are properly soldered and threaded.
