Compact metal box with six RJ45 ports fanless

NETGEAR ProSafe YS25-0402T 6-port network switch 4×2.5G 2×10G

SKU CH-4720-VN0MH MPN YS25-0402T

Six-port unmanaged switch with four 2.5 Gbps RJ45 ports and two 10 Gbps RJ45 ports, 60 Gbps switching capacity and one-key VLAN isolation

  • StandardsPassive PoE
  • Network MediaRJ45
  • Network Management TypeUnmanaged
  • Uplink InterfaceRJ45
  • Uplink Speed10/100 Mbps
  • Uplink Speed/TypeRJ45
  • 60 Gbps non-blocking capacity for 4K streaming and large file transfers
  • Four 2.5 Gbps RJ45 ports auto-negotiate 10/100/1000 Mbps and 2.5 Gbps speeds
  • Two 10 Gbps RJ45 uplink ports connect NAS and servers at full line rate
  • One-key VLAN isolates the four 2.5 Gbps ports while keeping uplink access
  • Fanless metal case operates silently from -10 °C to 55 °C

Six-port 2.5G and 10G switch

The NETGEAR ProSafe YS25-0402T is a six-port unmanaged Ethernet switch with four 2.5 Gbps RJ45 ports and two 10 Gbps RJ45 ports. It delivers a non-blocking switching capacity of 60 Gbps and a packet forwarding rate of 44.64 Mpps. The metal enclosure is fanless and supports wall mounting. It operates from an external 100 to 240 V AC power supply.

Home offices and small businesses needing

This switch suits users who want to connect 2.5 Gbps NAS devices, 10 Gbps servers or 2.5 Gbps PCIe adapters without configuring management software. The one-key VLAN mode isolates the four 2.5 Gbps ports from each other while keeping uplink access, useful for separating traffic from access points or IP cameras. Buyers who require managed features such as SNMP, port mirroring or link aggregation should look at a managed model instead.

60 Gbps switching capacity

The single specification that decides fit is the 60 Gbps non-blocking switching capacity. It determines whether the switch can handle simultaneous 2.5 Gbps and 10 Gbps flows without congestion. If your aggregated traffic stays below this ceiling the switch will perform as specified; if you need higher aggregate throughput you need a switch with a larger fabric.

Highlights

  • 60 Gbps non-blocking capacity for 4K streaming and large file transfers
  • Four 2.5 Gbps RJ45 ports auto-negotiate 10/100/1000 Mbps and 2.5 Gbps speeds
  • Two 10 Gbps RJ45 uplink ports connect NAS and servers at full line rate
  • One-key VLAN isolates the four 2.5 Gbps ports while keeping uplink access
  • Fanless metal case operates silently from -10 °C to 55 °C

Specifications

BrandNETGEAR
SeriesProSafe
Part NumberYS25-0402T-EU
StandardsPassive PoE
Network MediaRJ45
Network Management TypeUnmanaged
Uplink InterfaceRJ45
Uplink Speed10/100 Mbps
Uplink Speed/TypeRJ45
Primary Port Count6
Primary Ports16 x SFP + 8 x RJ45
Primary Port Speed10/100Mbps + 1000Mbps
Primary Port TypeRJ45
Management InterfaceRJ45
Management FeatureUser Manual, YuanLey 6-Port 2.5G Network Switch, Power Cable
Jumbo Frames9216 bytes
Packet Forwarding Rate60 gigabits_per_second
SNMPNo
Layer1
Layer 2 FeaturesRJ45, 60 gigabits_per_second, 6
Layer 3 Features6 Port / 4x2.5G +2x10G RJ45
CablingRJ45
Weight0.63 kilograms
Certificationnot_applicable
Features6, RJ45, User Manual, YuanLey 6-Port 2.5G Network Switch, Power Cable, 60 gigabits_per_second, black
Package ContentsUser Manual, YuanLey 6-Port 2.5G Network Switch, Power Cable

Questions about this item

Will the 60 Gbps switching capacity handle continuous 10 Gbps traffic on both uplink ports without bottlenecks?

The non-blocking 60 Gbps capacity supports full line-rate traffic across all six ports simultaneously, so both 10 Gbps uplinks and the four 2.5 Gbps ports can run at maximum speed without internal contention.

Does the fanless metal case stay cool enough for 24/7 operation in a 25 °C room?

The switch is rated for -10 °C to 55 °C ambient temperature; its fanless aluminium enclosure dissipates heat passively and is designed for continuous operation in typical office or home environments.

Which cables do I need to reach 2.5 Gbps and 10 Gbps on the RJ45 ports?

Cat6 or better UTP is required for both 2.5 Gbps and 10 Gbps links up to 150 metres; Cat5e only supports 1 Gbps on these ports.
