Silver 1U rack-mount switch with 24 RJ45 ports and four SFP+ cages

Netgear Inc.

Netgear Inc. XSM4324CS-100NES 24-port 10G managed network switch

SKU CH-WPHT-9C4A4 MPN XSM4324CS-100NES

24-port 10 Gigabit managed switch with 4 shared SFP+ uplinks, 480 Gbps non-blocking fabric and Layer 4 routing

  • FormatStackable
  • Network Management TypeManaged
  • Primary Ports24 x RJ45 + 2 x SFP+
  • Primary Port TypeHalf-Width 24 x 10G including 24 x 10GBASE-T and 4 x SFP+ (s
  • Buffer Memory32MB
  • ProtocolsTCP/IP
  • Managed 24-port 10G switch with 480 Gbps non-blocking fabric
  • Full Layer 4 feature set with non-stop forwarding stacking
  • Out-of-band 1G management port plus console and USB ports
  • Stackable 1U design fits standard racks at 1.73" height
  • Operates 0 to 50 °C with 90% max humidity

24-port 10G managed stackable switch

The Netgear ProSafe M4300-24X provides 24 RJ45 ports running at 10GBASE-T plus four shared SFP+ ports for 10GBASE-X fibre uplinks. A 480 Gbps non-blocking fabric across 24 ports keeps wire-speed throughput on every active link. Layer 4 management and an out-of-band 1G Ethernet management port give administrators full control without touching the data plane. It targets network teams building high-density 10G access layers in rack environments.

32 MB buffer and 480 Gbps fabric headroom

The 32 MB packet buffer absorbs burst traffic from multiple 10G endpoints simultaneously. The 480 Gbps non-blocking fabric sustains line-rate forwarding across all 24 RJ45 ports plus uplinks without oversubscription. Shared SFP+ ports trade fibre uplinks for copper density when all 24 RJ45 ports are populated. Operating temperature tops out at 50 °C, so sustained full-load deployments need adequate rack airflow.

No PoE support

This model delivers data only and does not supply Power over Ethernet to attached devices. Buyers who need to power wireless access points, IP cameras or VoIP phones from the switch must select a PoE-enabled variant. The 125 W maximum power draw covers the switch itself and its management functions.

Highlights

  • Managed 24-port 10G switch with 480 Gbps non-blocking fabric
  • Full Layer 4 feature set with non-stop forwarding stacking
  • Out-of-band 1G management port plus console and USB ports
  • Stackable 1U design fits standard racks at 1.73" height
  • Operates 0 to 50 °C with 90% max humidity

Specifications

BrandNETGEAR
SeriesProSafe
ModelXSM4324CS-100NES
FormatStackable
Network Management TypeManaged
Primary Ports24 x RJ45 + 2 x SFP+
Primary Port TypeHalf-Width 24 x 10G including 24 x 10GBASE-T and 4 x SFP+ (shared)
Buffer Memory32MB
ProtocolsTCP/IP
PoENo
Layer4
PowerPower Consumption: 125W max
Dimensions1.73" x 8.35" x 13.58"
Weight9.12 lbs.
TemperatureOperating temperature: 0 degree to 50 degree C (32 degree to 122 degree F)
Storage temperature: –20 degree to 70 degree C (– 4 degree to 158 degree F)
HumidityOperating Humidity: 90% maximum relative humidity, non-condensing
Storage Humidity: 95% maximum relative humidity, non-condensing
Features24-port 10GBASE-T (RJ45)
4-port 10GBASE-X (SFP+) (shared, back)
480 Gbps non-blocking fabric across 24 ports
Out-of-band 1G Ethernet management port
Mini-USB and RJ45 RS232 console ports and USB storage port
Full L3 feature set and non-stop forwarding (NSF) stacking
Half-width form factor with one- and two-unit rack mount kit
Two half-width switches can be installed in a single rack space for redundant top-of-rack
Ships with one modular APS250W PSU in its power supply slot
Low acoustics (37dB @ 25 degree C / 77 degree F)
Package ContentsPower cord (s)
RJ45 straight-through wiring serial console cable to DB9
Mini-USB console cable
Rubber caps for the SFP+ sockets
Rubber footpads for tabletop installation
Installation guide
Resource CD with the following manuals and software:
Software setup manual
CLI manual
Software administration guide
Hardware installation guide
The driver for use with The Mini-USB console cable
Shipping weight7.26 kg
Package size570 × 349 × 90 mm

Questions about this item

Will the 24 10GBASE-T RJ45 ports auto-negotiate with my existing 1 Gbps servers and NAS units?

Yes, the 24 RJ45 ports are 10GBASE-T and will negotiate link speed with connected 1 Gbps devices.

How can I verify the 480 Gbps non-blocking fabric is forwarding traffic correctly after configuration?

Use the out-of-band 1G management port to access the web or CLI interface and check port counters, LED status, and stacking health indicators.

Which cables and modules must I purchase separately to use the four shared SFP+ ports for 10G uplinks?

The box includes power cords, console cables, rubber caps, footpads, a guide and a resource CD; 10G SFP+ transceivers and fibre or DAC cables are not included.
