Silver metal 1U rack-mount switch with 48 RJ-45 ports and four SFP cages

Netgear Inc.

Netgear Inc. GS348TP-200NAS 48-port Gigabit PoE+ network switch

SKU CH-Z38K-SQXCK MPN GS348TP-200NAS

Provides 48 Gigabit PoE+ ports with a 380W budget and four SFP uplinks for fibre connectivity

  • FormatDesktop Rack-mountable
  • StandardsIEEE 802.3at IEEE 802.1x IEEE 802.1p IEEE 802.3az IEEE 802.1
  • Network MediaMedia Type Supported: Twisted Pair Optical Fiber Ethernet Te
  • Network Management TypeSmart Managed
  • Uplink PortsTotal Number of Network Ports: 48 Uplink Port: Yes Network (
  • Uplink InterfaceTotal Number of Expansion Slots: 4 Expansion Slot Type: SFP

Class 48 PoE+ (380W)

  • Power 48 devices with a 380 W PoE+ budget
  • Connect fibre uplinks through 4 dedicated SFP expansion slots
  • Manage traffic using L2/L3 features including VLANs and QoS
  • Configure the switch through an intuitive web browser interface
  • Reduce energy use with IEEE 802.3az Energy Efficient Ethernet

48-Port Gigabit PoE+ Switch for Business Networks

The Netgear GS348TP-200NAS is a Smart Managed Essentials switch built for business networks that need dense connectivity and power delivery. It provides 48 Gigabit Ethernet PoE+ ports and four dedicated SFP uplink slots in a desktop or rack-mountable format. The switch targets administrators who want L2/L3 Lite features such as VLANs, static routing and ACLs without the complexity of a full command-line stack. It is not suited for buyers who need a pure Layer 2 unmanaged switch or a higher PoE budget than 380 W.

Thermals Noise and Power Draw in Normal Use

The unit draws up to 431 W from its single internal power supply while delivering a 380 W PoE budget across the 48 RJ-45 ports. Energy Efficient Ethernet (IEEE 802.3az) reduces consumption on lightly loaded links, and the fan assembly scales speed to the thermal load of the chassis. Acoustic output will rise when many ports draw full PoE+ power simultaneously, so placement in a ventilated rack or on the supplied rubber footpads is recommended. No fan-less or silent-mode specification is provided.

Build Integration Needs and Freedoms

The switch occupies a standard 1U rack footprint and includes a rack-mount kit, while the bundled footpads allow stable tabletop installation. Four SFP slots accept 1000Base-X transceivers for fiber uplinks, freeing the copper ports for endpoint devices such as IP cameras, VoIP phones and wireless access points. A Kensington lock slot secures the hardware in shared spaces. The web-based GUI and optional Smart Control Center on Windows handle configuration, monitoring and multi-switch firmware upgrades without requiring a dedicated console cable.

Highlights

  • Power 48 devices with a 380 W PoE+ budget
  • Connect fibre uplinks through 4 dedicated SFP expansion slots
  • Manage traffic using L2/L3 features including VLANs and QoS
  • Configure the switch through an intuitive web browser interface
  • Reduce energy use with IEEE 802.3az Energy Efficient Ethernet

Specifications

BrandNETGEAR
SeriesS350
Part NumberGS348TP-200NAS
FormatDesktop
Rack-mountable
StandardsIEEE 802.3at
IEEE 802.1x
IEEE 802.1p
IEEE 802.3az
IEEE 802.1Q
IEEE 802.3ad
IEEE 802.3x
IEEE 802.1D
IEEE 802.1s
IEEE 802.1w
IEEE 802.1ab
IEEE 802.3
IEEE 802.3u
IEEE 802.3ab
IEEE 802.3af
IEEE 802.3z
Network MediaMedia Type Supported:
Twisted Pair
Optical Fiber
Ethernet Technology:
Gigabit Ethernet
Network Technology:
10/100/1000Base-T
1000Base-X
Maximum Data Transfer Rate:
128 MB/s
Network Management TypeSmart Managed
Uplink PortsTotal Number of Network Ports:
48
Uplink Port:
Yes
Network (RJ-45):
Yes
Port/Expansion Slot Details:
48 x Gigabit Ethernet PoE+ Network Port
4 x Gigabit Ethernet Expansion Slot
Uplink InterfaceTotal Number of Expansion Slots:
4
Expansion Slot Type:
SFP
Number of SFP Slots:
4
Layer3
PowerPoE (RJ-45) Port:
Yes
PoE Budget:
380 W
Power Source:
Power Supply
Number of Power Supplies Installed:
1
Power Consumption:
431 W
FeaturesAccess Control List
Quality of Service (QoS)
Auto Denial of Service (DoS) Prevention
IGMP Snooping
Port Mirroring
Energy Efficient
Remote Monitoring (RMON)
Kensington Lock Slot (K-slot)
DHCP Snooping
Broadcast Storm Control
Strict Priority Queuing (SPQ)
Application/Usage:
Network
Security
Traffic
PC
Surveillance
Business
Office
Wireless Access Point
Security Camera
IoT Devices
Video Surveillance
IP Phone
Router
VoIP Phone
Package ContentsGS348TPv2 Ethernet Switch
Power Adapter
Power Cord
Rackmount Kit
Rubber footpads for tabletop installation
Download Center Sheet (QR code)
Shipping weight5.81 kg
Package size526 × 404 × 104 mm

Other versions of this model

2 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I install the GS348TP in a rack and what step is often missed?

Use the supplied rackmount kit to secure the switch in a standard rack; the step often missed is also fitting the rubber footpads when the unit is used on a tabletop instead

What maintenance or replacement will the GS348TP need later?

The internal power supply and cooling fans are the components most likely to require replacement after extended operation

What limit appears first on the GS348TP under sustained heavy PoE load?

The 380 W PoE budget is the first constraint reached when many powered devices draw maximum current simultaneously
