Small rectangular SFP+ transceiver with silver metal body and RJ45 port

Netgear Inc.

Netgear Inc. AXM76520000S SFP transceiver 10GBASE-T 80 m

SKU CH-PBFN-0JAMN MPN AXM76520000S

Converts SFP+ or SFP28 slots to 10 Gb copper links up to 80 metres using Cat 6a or Cat 7 cable

  • Device TypeTransceiver
  • TemperatureOperating temperature 32–104ºF (0–40ºC)
  • HumidityOperative relative humidity 85% at 77ºF (25ºC)
  • FeatureOperating distance 10GBASE-T up to 262.5 ft (80 m) with Cat
  • Dimensions0.54 in. x 0.54 in. x 2.71 in. (13.8 mm x 13.7 mm x 68.8 mm)
  • Weight0.5 oz (14.17 g)
  • Delivers 10 Gb copper links up to 80 metres over Cat 6a or Cat 7
  • Hot-swappable SFP+ module installs or removes without powering down the switch
  • Low 2.5 W power draw keeps thermal load minimal in dense chassis
  • Operates reliably from 0 °C to 40 °C with 85 % humidity tolerance
  • Compliant with IEEE 802.3an, IEC/EN 60950-1, UL60950 and RoHS standards

What this transceiver does

The Netgear AXM76520000S converts an SFP+ or SFP28 slot on a managed switch into a 10GBASE-T copper port. It supports 10 Gb network connectivity over Category 6a or Category 7 cabling up to 80 meters. The module is automatically detected when inserted into a compatible switch.

Thermals, noise and power draw

The transceiver operates between 32°F and 104°F (0–40°C) at up to 85 percent relative humidity at 77°F (25°C). Power consumption is 2.5W. It carries IEC/EN 60950-1 and UL60950 safety certifications and meets RoHS environmental compliance. No moving parts are present.

Build fit and requirements

The module fits SFP+ and SFP28 interfaces on M4250, M4300 and M4500 managed switches. It uses an RJ45 connector and supports hot insertion or removal while the switch is running. Physical dimensions are 0.54 in. x 0.54 in. x 2.71 in. (13.8 mm x 13.7 mm x 68.8 mm) and weight is 0.5 oz (14.17 g).

Highlights

  • Delivers 10 Gb copper links up to 80 metres over Cat 6a or Cat 7
  • Hot-swappable SFP+ module installs or removes without powering down the switch
  • Low 2.5 W power draw keeps thermal load minimal in dense chassis
  • Operates reliably from 0 °C to 40 °C with 85 % humidity tolerance
  • Compliant with IEEE 802.3an, IEC/EN 60950-1, UL60950 and RoHS standards

Specifications

BrandNetgear
ModelAXM765
Device TypeTransceiver
TemperatureOperating temperature
32–104ºF (0–40ºC)
HumidityOperative relative humidity
85% at 77ºF (25ºC)
FeatureOperating distance
10GBASE-T up to 262.5 ft (80 m) with Cat 6a (or higher rated) Ethernet cable
Connectors
RJ45
Power consumption
2.5W
Safety certification
IEC/EN 60950-1, UL60950
Environmental compliance
RoHS
Dimensions0.54 in. x 0.54 in. x 2.71 in.
(13.8 mm x 13.7 mm x 68.8 mm)
Weight0.5 oz (14.17 g)
Shipping weight0.68 kg
Package size180 × 130 × 45 mm

Questions about this item

How do I install the AXM765 into an SFP+ slot, and what step is often missed?

Slide the transceiver into the SFP+ or SFP28 slot until it clicks; the step often missed is confirming the switch auto-detects the module before connecting the Cat 6a cable.

What maintenance or replacement will this transceiver need over time?

No scheduled maintenance is required; if the 2.5 W power draw causes thermal issues above 40 °C, replace the unit or improve chassis airflow.

What limit appears first during sustained 10 Gb traffic?

The 80 metre reach on Cat 6a or Cat 7 cable is the first bound; beyond that distance the link drops even if temperature stays within 0–40 °C.
