Small rectangular SFP transceiver module with black metal casing and LC duplex port

Netgear Inc.

Netgear Inc. AGM731F SFP transceiver 1000Base-SX LC 550m

SKU CH-XJX7-QBQGH MPN AGM731F

Adds 1000Base-SX fibre connectivity to Netgear managed switches with LC duplex connector supporting up to 550 m over OM3 multi-mode fibre

  • Device TypeTransceiver
  • StandardsAGM731F: IEEE 802.3z, 1000Base-SX
  • Ports1000Base-SX
  • TemperatureStorage temperature -40–185ºF (–40–85ºC) Case operating temp
  • HumidityOperative relative humidity 85% at 77ºF (25ºC)
  • FeatureConnectors LC for 62.5/125µm or 50/125µm cable Operating Dis
  • Gigabit Ethernet links up to 550 m over OM3 multimode fibre
  • Plugs directly into any NETGEAR fully managed switch SFP slot
  • Module auto-detected on insertion for immediate operation
  • Low 1.1 W power draw reduces switch thermal load
  • LC duplex connector supports 62.5/125 µm OM1 and 50/125 µm OM2/OM3 cables

SFP transceiver for managed switches

This Netgear AGM731F module adds 1000Base-SX fiber connectivity to any NETGEAR Fully Managed Switch with an SFP slot. It provides full-duplex Gigabit Ethernet operation and is automatically recognised when inserted. The LC duplex connector accepts 62.5/125µm or 50/125µm multimode cables. Power draw is 1.1W.

Multi-mode fiber links up to 550 m

The transceiver suits installers who need to link switches over OM1, OM2 or OM3 multimode fiber within a building or campus. Reach is 275 m on OM1, 275–550 m on OM2 and 550 m on OM3. It is not for single-mode fiber runs, nor for 10G or faster uplink requirements. Buyers needing longer distances or different wavelengths should look elsewhere.

Operating temperature range -5 °C to 70 °C

The case operating temperature spans 23–158 °F (-5–70 °C), which determines whether the module can stay reliable inside a given switch chassis or cabinet. Storage tolerance is wider at -40–185 °F (-40–85 °C). If the installation environment exceeds the operating limits, a different transceiver class will be required.

Highlights

  • Gigabit Ethernet links up to 550 m over OM3 multimode fibre
  • Plugs directly into any NETGEAR fully managed switch SFP slot
  • Module auto-detected on insertion for immediate operation
  • Low 1.1 W power draw reduces switch thermal load
  • LC duplex connector supports 62.5/125 µm OM1 and 50/125 µm OM2/OM3 cables

Specifications

BrandNetgear
ModelAGM731F
Device TypeTransceiver
StandardsAGM731F: IEEE 802.3z, 1000Base-SX
Ports1000Base-SX
TemperatureStorage temperature
-40–185ºF (–40–85ºC)
Case operating temperature
23–158ºF (–5–70ºC)
HumidityOperative relative humidity
85% at 77ºF (25ºC)
FeatureConnectors
LC for 62.5/125µm or 50/125µm cable
Operating Distance Multi-Mode Fiber (MMF)
OM1: 900 ft (275 m)
OM2: 900–1,800 ft (275–550 m)
OM3: 1,800 ft (550 m)
Power Consumption
1.1W
MTBF
>10 years
Safety Certification
UL 60950-1, CSA-C22.2 No.60950-1
Environmental Compliance
RoHS
DimensionsAGM731F: 2.23 x 0.53 x 0.34 in (56.8 x 13.6 x 8.6 mm)
WeightAGM731F: 0.58 oz (16.3 g)
DisclaimerWARNING: Because invisible laser radiation might be emitted from the aperture of the port when no fiber cable is connected, avoid exposure to laser radiation and do not stare into open apertures.
Shipping weight0.11 kg
Package size178 × 130 × 46 mm

Questions about this item

How do I install this SFP module into a Netgear managed switch?

Slide the AGM731F into any free SFP slot until it clicks; the switch auto-detects the module so no software configuration is needed.

What maintenance or replacement will the AGM731F need over time?

The module has an MTBF of more than 10 years and no user-serviceable parts, so replacement is only required if the unit fails.

What distance limit appears first when running this transceiver continuously on OM1 fiber?

OM1 multimode fiber caps the link at 275 metres, which is the shortest supported reach for this module.
