Motorola
Motorola WT41N0-T2H27ER wearable mobile computing, dual-core OMAP 4 1GHz, 512MB/2GB, Windows CE 7.0
A rugged wearable terminal with dual-core OMAP 4 processor, Windows CE 7.0, 512MB RAM, 2GB Flash, touch screen, 802.11 a/b/g/n Wi-Fi and Bluetooth 2.1, rated IP54 for warehouse use
- StyleWearable
- CPUDual Core OMAP 4 @ 1GHz
- Operating SystemWindows CE 7.0
- Memory512MB RAM / 2GB Flash
- Resolution320x240
- Display TypeQVGA
- Hands-free operation with wearable form factor
- Dual-core 1 GHz processor powers voice and data tasks
- 512 MB RAM and 2 GB flash run Windows CE 7.0
- IP54 sealing plus 1.2 m drop rating survive harsh environments
- 11 a/b/g/n Wi-Fi and Bluetooth 2.1 keep workers connected
Rugged wearable terminal for warehouse operations
The WT41N0-T2H27ER is a hip- or wrist-mounted mobile computer built for voice and data tasks in distribution centres. It runs Windows CE 7.0 on a dual-core OMAP 4 processor at 1 GHz with 512 MB RAM and 2 GB flash storage. The 320 x 240 QVGA touch screen and backlit two-colour keypad support gloved operation in low light.
Simple mounting but accessories sold separately
The unit weighs 0.82 lb with the extended battery fitted and measures 1.00 x 3.70 x 5.70 inches, so it straps to the arm without special tools. Interface cables and charging cradles are not included and must be ordered separately. The IP54 rating protects against dust and splashing water, yet the touch layer can be scratched if cleaned with abrasive cloths.
Stable throughput across full temperature range
Wireless LAN 802.11 a/b/g/n and Bluetooth 2.1 maintain connections while workers move between cold storage at -22 °F and loading docks at 122 °F. The dual-core architecture keeps voice-directed picking applications responsive during continuous shifts. Humidity tolerance of 5 % to 95 % non-condensing prevents condensation-related lockups during rapid zone changes.
Highlights
- Hands-free operation with wearable form factor
- Dual-core 1 GHz processor powers voice and data tasks
- 512 MB RAM and 2 GB flash run Windows CE 7.0
- IP54 sealing plus 1.2 m drop rating survive harsh environments
- 11 a/b/g/n Wi-Fi and Bluetooth 2.1 keep workers connected
Specifications
| Brand | Motorola |
|---|---|
| Model | WT41N0 |
| Part Number | WT41N0-T2H27ER |
| Style | Wearable |
| CPU | Dual Core OMAP 4 @ 1GHz |
| Operating System | Windows CE 7.0 |
| Memory | 512MB RAM / 2GB Flash |
| Resolution | 320x240 |
| Display Type | QVGA |
| Keypad | 2-Color Keypad |
| Touch Screen | Yes |
| Backlit Keys | Yes |
| Wireless LAN | IEEE 802.11 a/b/g/n |
| Bluetooth | Bluetooth 2.1 + EDR |
| Drop Rating | Multiple drops to concrete: 4 ft. / 1.2 m across the operating temperature range |
| IP Rating | IP54 |
| Operating Temperature | -4° to 122° F/-20° to 50° C -22° to 122° F/-30° to 50° C |
| Humidity | 5% to 95% non-condensing |
| Dimensions | 1.00" x 3.70" x 5.70" |
| Weight | Terminal w/ Extended Battery: 0.82 lb. (0.53 lb. + 0.29 lb.) |
| Shipping weight | 0.43 kg |
| Package size | 254 × 254 × 254 mm |
Questions about this item
How do I verify the WT41N0 is operating correctly after initial setup?
Power on the terminal, confirm the QVGA touch screen displays the Windows CE 7.0 desktop at 320x240 resolution, test the 2-color backlit keypad response, and validate wireless LAN association with your 802.11 a/b/g/n network.
What ships with the WT41N0-T2H27ER and what must be purchased separately?
The unit includes the wearable terminal with extended battery (0.82 lb total), dual-core OMAP 4 processor, 512MB RAM, 2GB Flash, touch screen, and Bluetooth 2.1 radio. Interface cables and charging cradle are sold separately.
Which WT41N0 configuration suits high-volume voice-directed picking in cold storage?
The T2H27ER model provides Windows CE 7.0 on a dual-core 1GHz OMAP 4 with 512MB RAM/2GB Flash, IP54 sealing, and a -30°C to 50°C operating range, supporting extended-battery shifts in freezer environments.
