Small black square mini PC with rounded edges and vented sides

minisforum

minisforum MS-A2 DeskMini Ryzen 7 7745HX 32GB 1TB barebone mini PC

SKU CH-R3CV-W2TQH

Compact barebone mini PC with an 8-core Ryzen 7 7745HX, 32 GB DDR5, 1 TB storage, dual 2.5 GbE and 10 GbE SFP+ ports, plus triple 8K display output

  • ColorBlack
  • CPU TypeAMD Ryzen 7 7745HX
  • CPU SocketFL1
  • CPU Cores8-Core
  • Memory installed32GB
  • Memory slot2

Option MSA2-7745 · 32+1T

  • 8-core Ryzen 7 7745HX up to 5.1 GHz handles heavy workloads
  • 32 GB DDR5-5200 installed, expandable to 96 GB dual-channel
  • 1 TB NVMe plus three PCIe 4.0 x4 M.2 slots for massive storage
  • Dual 2.5 GbE RJ45 and 10 GbE SFP+ for ultra-fast networking
  • HDMI and two USB-C ports drive three 8K 60 Hz displays

Compact workstation with Ryzen 7 7745HX

The minisforum MS-A2 DeskMini is a barebone mini PC built around an 8-core AMD Ryzen 7 7745HX processor that reaches 5.1 GHz. It ships with 32 GB of DDR5 5200 memory in dual-channel configuration and a 1 TB SSD. Integrated AMD Radeon 610M graphics drive up to three displays via HDMI and two USB-C ports, each capable of 8K at 60 Hz.

Replaces a tower workstation for multi-display

The system upgrades from a traditional desktop by packing dual 2.5 GbE RJ45 ports and a 10 G SFP+ port into a 7.72 x 7.44 x 1.89 inch chassis weighing 3.17 lb. Four PCIe 4.0 x4 lanes and support for M.2 2280, 22110 and U.2 NVMe drives let you add high-speed storage without a full-size case. The jump is worth it when you need 10 G networking and triple 8K output in a footprint that fits behind a monitor.

Verify power, memory and storage plans before

The unit includes a 19 V 12.63 A 240 W power supply, so confirm your regional plug or adapter needs. Two SODIMM slots accept DDR5 5200 up to 96 GB total; populate both for dual-channel bandwidth. Three PCIe 4.0 x4 slots are available for expansion cards, but physical clearance inside the 1.89 inch height may limit card thickness. Wireless connectivity uses Wi-Fi 6E and Bluetooth 5.2.

Highlights

  • 8-core Ryzen 7 7745HX up to 5.1 GHz handles heavy workloads
  • 32 GB DDR5-5200 installed, expandable to 96 GB dual-channel
  • 1 TB NVMe plus three PCIe 4.0 x4 M.2 slots for massive storage
  • Dual 2.5 GbE RJ45 and 10 GbE SFP+ for ultra-fast networking
  • HDMI and two USB-C ports drive three 8K 60 Hz displays

Specifications

BrandMINISFORUM
ModelDeskMini
ColorBlack
CPU TypeAMD Ryzen 7 7745HX
CPU SocketFL1
CPU Cores8-Core
Memory installed32GB
Memory slot2
Memory Type SupportedDDR5 5200
Max Memory Supported96GB
Dual Channel Memory SupportedYes
Other3x PCIe4.0x4
Integrated GraphicsAMD Radeon 610M
Max LAN Speed2.5Gbps
Wireless LAN802.11ax
WiFi GenerationWi-Fi 6E
BluetoothBluetooth 5.2
Front USB3
HDMI1
Rear USB2
RJ452
Power Supply19V/12.63A 240W
Dimensions7.72x7.44x1.89inch
Weight3.17lb

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will the 7.72 x 7.44 x 1.89 inch chassis fit on a standard VESA mount?

The unit measures 7.72 x 7.44 x 1.89 inches and weighs 3.17 lb; check the bracket specifications for exact VESA hole spacing and weight limits.

Which screw secures the M.2 2280 drive during installation?

The M.2 2280 slot uses a single retention screw; insert the drive at an angle, press down, and tighten that screw — skipping it is the common mistake.

Can the pre-installed 32 GB DDR5 5200 memory be upgraded later?

Yes, two SODIMM slots support up to 96 GB total of DDR5 5200; add or replace modules in matched pairs for dual-channel operation.
