Cylindrical glass-fibre fuse, transparent body, 5-5/8 in long, 13/16 in diameter

Mersen

Mersen A480T1E 1A 4.8kV Time-Delay Cylindrical Fuse

SKU CH-VS8N-R53Q7

A 1 A, 4.8 kV time-delay cylindrical fuse with a 50 kA interrupt rating for medium-voltage circuit protection

  • TypeFuses & Accessories
  • ColorTransparent
  • Time-delay characteristic prevents nuisance trips on transient surges
  • Class E-rated for 4.8 kV AC medium-voltage systems
  • 50 kA interrupting capacity at 4800 V AC handles severe faults
  • Glass fiber-reinforced melamine body resists thermal and mechanical stress
  • Cylindrical 5-5/8 in × 13/16 in form factor fits standard holders

Medium Voltage Fuse 1 A 4.8 kV

The Mersen A480T1E is a cylindrical medium-voltage fuse rated at 1 A and 4.8 kV AC. It belongs to the A480T series with a Class E rating and a time-delay characteristic. The fuse has an interrupt rating of 50 kA symmetrical at 4800 V AC. It is designed for non-indicating, non-rejection applications in electrical systems.

Voltage Rating And Series Compatibility

Verify that your circuit operates at or below 4.8 kV AC and requires a Class E-rated, time-delay fuse. The A480T series uses a cylindrical body style with non-rejection mounting. Confirm the available holder accepts a 5-5/8 in length by 13/16 in diameter fuse. Cross-reference the Bussmann AMWNA equivalent series only if your documentation specifies it.

Glass Fiber Reinforced Melamine Body

The fuse body is constructed from glass fiber-reinforced melamine for insulation and mechanical strength. A single-element design provides the time-delay response without an indicator flag. No additional accessories or software are bundled with this fuse. The transparent color allows visual inspection of the element through the tube.

Highlights

  • Time-delay characteristic prevents nuisance trips on transient surges
  • Class E-rated for 4.8 kV AC medium-voltage systems
  • 50 kA interrupting capacity at 4800 V AC handles severe faults
  • Glass fiber-reinforced melamine body resists thermal and mechanical stress
  • Cylindrical 5-5/8 in × 13/16 in form factor fits standard holders

Specifications

BrandMERSEN
TypeFuses & Accessories
ColorTransparent

Questions about this item

What comes in the box and do I need any extra hardware to install the Mersen A480T1E fuse?

The fuse is supplied as a single cylindrical unit with glass fibre-reinforced melamine body; no additional hardware is included, so you must provide compatible fuse clips or a holder rated for 4.8 kV AC.

How do I choose the correct version of this fuse for my application?

Select the A480T1E when you need a 1 A, 4.8 kV AC, Class E-rated, time-delay fuse with a 50 kA interrupt rating at 4800 V AC and a 5-5/8 in by 13/16 in cylindrical body.

What does the 50 kA interrupt rating mean once the fuse is fitted in a real circuit?

It means the fuse can safely break a prospective short-circuit current of up to 50 kA at 4800 V AC without rupturing, protecting downstream equipment during a fault.
