Small rectangular USB-C tester with colour TFT screen, male plug on one end, female port on the other, matte black plastic body

MakerHawk USB C Tester 0-30V 0-6.5A TFT Color Display

SKU CH-NWSN-5SYRV

Monitors USB-C voltage, current, capacity, power, temperature, impedance and charging time up to 30 V and 6.5 A on an 8192-pixel TFT colour display that flips 180°

  • FeaturesUSB C Tester, Qualcomm, Corded Electric, false
  • Height7.2 L x 3.18 W x 1.24 H centimeters
  • Width7.2 L x 3.18 W x 1.24 H centimeters
  • Length7.2 L x 3.18 W x 1.24 H centimeters
  • Weight18 grams
  • Sports Team1 Piece
  • Monitor voltage, current, power, capacity, temperature and impedance with 8192-pixel TFT colour display
  • Measure up to 30 V and 6.5 A on USB-C and USB-A ports
  • Flip screen 180 degrees for upright reading on inverted chargers
  • Set over-voltage, under-voltage, over-current and backlight timers via front button
  • Built-in PD protocol triggers charger output for no-load ageing tests

USB-C power meter with colour TFT

This MakerHawk tester measures DC voltage from 0 to 30 V and current up to 6.5 A through a USB-C male plug. The 8192-pixel colour display shows voltage, current, capacity, energy, power, temperature, load impedance, D+/D- voltage and charging time. It supports PD 2.0, PD 3.0, QC 2.0, QC 3.0 and Apple 2.4 A quick-charge protocols plus OTG function.

Check your charger and cable ratings

Verify that the source you intend to test does not exceed 30 V or 6.5 A, otherwise the meter could be damaged. Ensure the USB-C plug orientation suits your port; the screen can be flipped 180 degrees if the charger mounts upside-down. The unit weighs 18 grams and measures 7.2 by 3.18 by 1.24 centimetres, so confirm there is enough clearance around the socket.

Replaces basic USB voltmeters without protocol

Older single-function meters only show voltage and current, while this model adds capacity, energy, impedance and D+/D- readings. The jump is worth it when you need to confirm fast-charge handshake, monitor temperature rise or log charge time automatically. It is not for users who require Bluetooth logging, multi-port simultaneous measurement or AC mains analysis.

Highlights

  • Monitor voltage, current, power, capacity, temperature and impedance with 8192-pixel TFT colour display
  • Measure up to 30 V and 6.5 A on USB-C and USB-A ports
  • Flip screen 180 degrees for upright reading on inverted chargers
  • Set over-voltage, under-voltage, over-current and backlight timers via front button
  • Built-in PD protocol triggers charger output for no-load ageing tests

Specifications

BrandMakerHawk
FeaturesUSB C Tester, Qualcomm, Corded Electric, false
Height7.2 L x 3.18 W x 1.24 H centimeters
Width7.2 L x 3.18 W x 1.24 H centimeters
Length7.2 L x 3.18 W x 1.24 H centimeters
Weight18 grams
Sports Team1 Piece
TypeAmp Meters & Probes

Questions about this item

What comes in the box and do I need any extra cables to start testing?

The tester itself is supplied as a single piece weighing 18 grams with an integrated USB-C male plug and a standard USB-A socket, so no separate cable is required to begin measuring.

Which measurement range should I select for a typical phone charger that delivers up to 30 V and 6.5 A?

The single model covers the full 0-30 V and 0-6.5 A span, so one unit handles every common USB-C power profile without needing a higher-range variant.

What does the 8192-pixel TFT colour display actually show while a device is charging?

It reports real-time voltage, current, capacity, energy, power, temperature, load impedance, D+/D- voltage and charging time, and flips 180 degrees for upside-down ports.
