Macromatic TR-51628-10 off delay relay, octal 11 pin plug-in, enclosed IP20 housing

Macromatic

Macromatic TR-51628-10 Off Delay Relay

SKU CH-798T-WNBG5

A plug-in off-delay relay with DPDT contacts rated 10 A at 240 V AC or 30 V DC, adjustable from 1.8 s to 3 min on a 24 V AC/DC coil

  • Adjustable timing from 1.8 seconds to 3 minutes via potentiometer
  • 10 amp DPDT contacts switch 240 V AC or 30 V DC loads
  • Plug-in octal base with 11 pins for quick socket mounting
  • Operates on 24 V AC or DC coil voltage for flexible control circuits
  • IP20 enclosed housing protects internal components in panel installations

Macromatic TR-51628-10 Off Delay Relay

This Macromatic TR-51628-10 is a single-function time delay relay designed for industrial control circuits. It provides an off-delay function with a potentiometer adjustment method for timing control.

Suits panels needing a plug-in octal relay

Installers who need a compact, enclosed relay for 24V AC/DC systems with a 1.8 second to 3 minute off-delay range will find this suitable. Buyers who require multiple delay functions or a different contact form should look at other models.

Handles 10 A at 240V AC

The relay comfortably switches resistive loads up to the rated 10 A within the specified voltage limits. It runs out of headroom for loads exceeding 10 A or for applications needing time settings outside the 1.8 second to 3 minute window.

Highlights

  • Adjustable timing from 1.8 seconds to 3 minutes via potentiometer
  • 10 amp DPDT contacts switch 240 V AC or 30 V DC loads
  • Plug-in octal base with 11 pins for quick socket mounting
  • Operates on 24 V AC or DC coil voltage for flexible control circuits
  • IP20 enclosed housing protects internal components in panel installations

Specifications

BrandMACROMATIC

Questions about this item

What socket or base do I need to plug the 11-pin octal relay into?

The relay uses an 11-pin octal plug-in base; wire the socket first, then insert the relay.

Will the 24 V AC/DC coil work with my existing 24 V control circuit?

Yes, the coil is rated for 24 V AC or DC, so it operates directly from a 24 V control supply.

How can I verify the off-delay timing is set correctly after wiring?

Apply power, then remove it; the DPDT contacts should stay closed for the potentiometer-set interval between 1.8 sec and 3 min before opening.
