Macromatic TR-51626-12 octal plug-in relay, 11 pins, IP20 enclosure

Macromatic

Macromatic TR-51626-12 Off Delay Time Delay Relay

SKU CH-MPA5-J86HZ

An off-delay time relay with potentiometer adjustment from 3 seconds to 5 minutes, 12 V DC coil, DPDT contacts rated 10 A at 240 V AC or 30 V DC, 11-pin octal plug-in base

  • Off-delay timing adjustable from 3 seconds to 5 minutes
  • DPDT contacts rated 10 A at 240 V AC and 30 V DC
  • 12 V DC coil voltage matches common control circuits
  • Plug-in octal base with 11 pins for quick socket mounting
  • Enclosed IP20 housing protects internal components

Off-Delay Relay for 12 V DC Control

This single-function Macromatic TR-51626-12 relay provides an off-delay timer for 12 V DC circuits. It suits control panels and machinery that need a load to remain energised for a set period after the input signal is removed. The DPDT contacts switch up to 10 A at 240 V AC or 30 V DC.

Timing Range Limited to Three Seconds Through Five

The potentiometer adjusts the delay between a minimum of three seconds and a maximum of five minutes. Applications that require sub-second precision or delays longer than five minutes cannot use this device. The fixed 12 V DC coil voltage also means the unit cannot be operated on 24 V or mains supplies without an external power supply.

Plug-In Octal Socket With Eleven Pins

Installation is a simple push-fit into a standard octal socket using the eleven flat pins. The enclosed IP20 housing protects the internals but offers no sealing against water or dust ingress. Mis-wiring the DPDT contacts or applying a coil voltage above 12 V DC are the most common errors that cause premature failure.

Highlights

  • Off-delay timing adjustable from 3 seconds to 5 minutes
  • DPDT contacts rated 10 A at 240 V AC and 30 V DC
  • 12 V DC coil voltage matches common control circuits
  • Plug-in octal base with 11 pins for quick socket mounting
  • Enclosed IP20 housing protects internal components

Specifications

BrandMACROMATIC

Questions about this item

What is the adjustable time range for the off-delay function on this relay?

The relay adjusts from a minimum of 3 seconds up to a maximum of 5 minutes using the built-in potentiometer.

How much current can the DPDT contacts switch at the rated 12 V DC coil voltage?

The contacts are rated for 10 A at 30 V DC and 10 A at 240 V AC, so they handle 10 A at the coil voltage.

What socket type does the 11-pin octal base require for installation?

The plug-in relay uses an 11-pin octal socket with flat-pin connections for standard panel mounting.
