Macromatic TR-50226-10 contactor 12 V DC 10 A DPDT 1.8 s
Single-function on-delay timer relay with 12 V DC coil, DPDT contacts rated 10 A, adjustable 1.8 s to 3 min, plug-in octal base
- Precise timing control with adjustable 1.8 second to 3 minute delay range
- Versatile 12 V DC operation compatible with standard automotive and industrial systems
- Reliable DPDT switching handles 10 A loads at both 240 V AC and 30 V DC
- Quick plug-in installation via 8-pin octal socket for minimal downtime
- Protected IP20 enclosed housing safeguards internal components in demanding environments
Single-Function On-Delay Relay
The Macromatic TR-50226-10 is a single-function time delay relay designed for control circuits requiring a fixed on-delay sequence. It operates on a 12 V DC input voltage and switches loads through DPDT contacts rated at 10 A. The unit plugs into an octal socket for straightforward installation in panels or machinery.
Adjustable Timing From 1.8 Seconds To Three Minutes
The delay period is set via an onboard potentiometer covering a range from 1.8 sec up to 3 min. The enclosed housing carries an IP20 rating, protecting internal components from finger contact and solid objects. Coil power is drawn from a 240 V AC source while the control input remains at 12 V DC, keeping operational power draw low and noise negligible in typical cabinet environments.
Replaces Fixed-Timer Or Manual Switching Setups
This relay upgrades applications that currently rely on non-adjustable timers or simple manual switches by adding a user-settable delay without rewiring the socket. The jump is worthwhile when a process needs a precise start-up pause between 1.8 sec and 3 min and the existing hardware cannot be recalibrated. It does not suit designs needing multiple delay functions, instantaneous switching, or contact ratings above 10 A at 240 V AC or 30 V DC.
Highlights
- Precise timing control with adjustable 1.8 second to 3 minute delay range
- Versatile 12 V DC operation compatible with standard automotive and industrial systems
- Reliable DPDT switching handles 10 A loads at both 240 V AC and 30 V DC
- Quick plug-in installation via 8-pin octal socket for minimal downtime
- Protected IP20 enclosed housing safeguards internal components in demanding environments
Specifications
| Brand | MACROMATIC |
|---|
