LUOM TJ-A0126 USB-C 4K@60Hz 8K KVM Switch DP 1.4 USB 2.0 Hub
Shares one DisplayPort monitor and three USB 2.0 devices between two USB-C computers at up to 8K 60 Hz or 4K 144 Hz
- TypeDisplayPort, USB
- PC ConnectorsUSB-C cable
- Computer Connections2 Ports
- Monitor Connections1 Port
- Video Resolution7680×4320
- PC SelectionManual Switch
- Share two USB-C PCs on one DisplayPort 1.4 monitor up to 7680×4320
- Switch instantly with the front button or 3-second auto-scan
- Three USB 2.0 ports let keyboard, mouse and printer follow the active PC
- 4 Gbps DisplayPort 1.4 bandwidth carries 4K@144Hz and 8K@60Hz
- Compact 5.43×5.35×1.46 in unit includes two USB-C Gen-2 cables and power lead
LUOM TJ-A0126 dual USB-C KVM switch
The LUOM TJ-A0126 is a two-port KVM switch that lets two USB-C computers share one DisplayPort 1.4 monitor and up to three USB 2.0 peripherals. A front-panel button selects the active system instantly. The unit ships with two USB-C Gen-2 cables and a USB-A to USB-C power cable.
Suits dual-computer workstations with DP monitors
Users who need to drive a single DisplayPort display from two USB-C laptops or desktops will find the switch fits directly. Builders whose monitors rely on HDMI or who require USB 3.x peripheral bandwidth should look at a different solution.
8K60 DisplayPort 1.4 video path
The switch passes 7680×4320 at 60 Hz and 4K at 144 Hz through its single DisplayPort 1.4 output, backed by 32.4 Gbps video bandwidth. This resolution ceiling determines whether your monitor and GPU combination can be driven at full quality.
Highlights
- Share two USB-C PCs on one DisplayPort 1.4 monitor up to 7680×4320
- Switch instantly with the front button or 3-second auto-scan
- Three USB 2.0 ports let keyboard, mouse and printer follow the active PC
- 4 Gbps DisplayPort 1.4 bandwidth carries 4K@144Hz and 8K@60Hz
- Compact 5.43×5.35×1.46 in unit includes two USB-C Gen-2 cables and power lead
Specifications
| Brand | LUOM |
|---|---|
| Series | TJ-A0126 |
| Model | TJ-A0126 |
| Type | DisplayPort, USB |
| PC Connectors | USB-C cable |
| Computer Connections | 2 Ports |
| Monitor Connections | 1 Port |
| Video Resolution | 7680×4320 |
| PC Selection | Manual Switch |
| AutoScan Interval | 3 seconds |
| Bandwidth | DP 1.4: 32.4Gbps/USB 2.0: 480Mbps |
| LED Indicators | Yes |
| Application | 2PC Share 1 Monitor and One Keyboard Mouse,KVM Switch Displayport,Support 8K@60Hz 4K@144Hz 3D 1080P |
| Features | 2xUSB-C 8K KVM Switch with one DisplayPort 1.4 Port for Video,with this 2 Port 8K KVM Switcher,you are able to connect from the switcher's two PC Input Port to your USB-C PC/Laptops via two standard USB-C Gen-2 Cable,then connect from the switcher's Standard DP 1.4 Port to your DisplayPort Monitors via your own displayport 8k Standard Cable,you can press the "select"button to switch between two of your PCs.Note:You must plug our USB C to USB A cable to power the switcher while working With 3xUSB2.0 Output Port,two Computers share one set,you can connect 3xUSB2.0 Output to your USB Mo |
| Dimensions | 5.43 x 5.35 x 1.46 inches |
| Weight | 9.52 Ounces |
| Package Contents | 1 x DP KVM Switch, 2 x USB-C Cable, 1 x USB-A to USB-C power cable |
Questions about this item
Will the USB-A to USB-C power cable need replacing if it frays?
The included USB-A to USB-C cable powers the unit; any standard USB-A to USB-C cable can replace it if the original frays.
Does the 480 Mbps USB 2.0 bandwidth limit file transfers when switching PCs?
Yes, the three USB 2.0 ports share a 480 Mbps link, so large file copies will be slower than on USB 3.0 ports.
How warm does the 5.43 × 5.35 × 1.46 inch enclosure get during all-day 8K@60Hz use?
The compact metal case runs warm but stays within safe limits; no fan is fitted, so keep ventilation clear around the 1.46 inch height.
