LUOM
LUOM SW241-HD 4-port HDMI KVM switch 8K 60Hz
Connects four computers to one monitor at 8K 60 Hz with four USB 3.0 ports and push-button or remote switching
- TypeHDMI, USB
- PC ConnectorsHDMI, USB
- Computer Connections4 Port - USB 3.0 HDMI
- Monitor Connections1 Port
- Video Resolution8K 60Hz
- PC SelectionPush Buttons/Desktop Controller
- Controls four computers with one keyboard and mouse
- 8K 60 Hz video through HDMI 2.1 ports
- Four USB 3.0 ports share peripherals at 5 Gbps
- Push-button, remote and auto-scan switching
- 12 V power supply included for stable operation
Four-computer HDMI KVM switch
The LUOM SW241-HD lets four computers or laptops share one monitor and four USB 3.0 peripherals. You control every system with a single keyboard and mouse. Switching is handled by front-panel buttons or the included wired desktop controller. The unit ships with four USB 3.0 A-to-A cables, a 12 V 1 A power supply, an IR cable, a remote control and a manual.
HDMI 2.1 bandwidth and resolution limits
Video passes through an HDMI 2.1 interface rated for 8K at 60 Hz and 4K at 120 Hz. Both the source graphics card and the display must support the target resolution and refresh rate. A certified Ultra High Speed HDMI 2.1 cable is required for 8K 60 Hz operation and is not included. The switch is backward compatible with earlier HDMI standards.
Plug-and-play installation and common issues
No driver installation is needed; connect the cables, apply power and the switch is ready. Auto-scan cycles through ports every 3 seconds if enabled. The most frequent problems are using cables that do not meet the HDMI 2.1 specification, forgetting the external power adapter, or connecting a monitor or GPU that lacks 8K 60 Hz support.
Highlights
- Controls four computers with one keyboard and mouse
- 8K 60 Hz video through HDMI 2.1 ports
- Four USB 3.0 ports share peripherals at 5 Gbps
- Push-button, remote and auto-scan switching
- 12 V power supply included for stable operation
Specifications
| Brand | LUOM |
|---|---|
| Series | SW241-HD |
| Model | SW241-HD |
| Type | HDMI, USB |
| PC Connectors | HDMI, USB |
| Computer Connections | 4 Port - USB 3.0 HDMI |
| Monitor Connections | 1 Port |
| Video Resolution | 8K 60Hz |
| PC Selection | Push Buttons/Desktop Controller |
| AutoScan Interval | 3 seconds |
| LED Indicators | Yes |
| USB Features | with USB support |
| Application | The hdmi kvm switch 4 port allows 4 computers or laptops to share 1 monitor and 4 USB 3.0 devices. You can control all 4 computers directly with a single set of mouse and keyboard. Switching between the 4 computers is easy using the panel buttons or an external remote. It's plug-and-play, streamlining your workspace and boosting office efficiency. |
| Features | 4 in 1 out HDMI KVM Switch: HDMI KVM Switch is a HDMI switch that help 4 computers/laptops to share 1 monitor and 4 USB 3.0 devices such as scanner, printer, mouse, keyboard. ? 4 computers/laptops share one set of keyboard, mouse and 1 monitors, and more USB 3.0 peripherals; Support maximum resolution up to 4K 120Hz HDMI monitors output support up to 8K@60Hz/4K@120Hz,2K@144Hz/1080P@240Hz for mirrored display; Compatible with Windows 11/10/7/2000/XP/Vista, Linux, UNIX, Ubuntu, Fedora, and other systems; Advanced switching modes: push button and IR remote control;No complicated install |
| Dimensions | 5.43 x 5.35 x 1.46 inches |
| Weight | 9.52 Ounces |
| Package Contents | You will receive a 1*4 in 1 out KVM switcher, 4*USB 3.0 A to A cables, 1*12V1A external power supply, 1*IR cable, 1*remote control (excluding battery), and 1*user manual. |
Questions about this item
How do I decide whether the LUOM SW241-HD is the right KVM for my four-computer setup?
Choose this model when you need to share one monitor and four USB 3.0 peripherals across four HDMI-equipped computers, with push-button or remote switching.
What does the 8K 60 Hz rating mean when I connect my PC and monitor?
It means the switch can pass an 8K signal at 60 Hz or 4K at 120 Hz, provided both your graphics card and monitor support those modes and you use an HDMI 2.1 cable.
Which HDMI standard does the switch use and what bandwidth limit does it impose?
The unit uses HDMI 2.1 ports, capping video at 8K 60 Hz or 4K 120 Hz while USB 3.0 peripherals run at up to 5 Gbps.
