LUOM
LUOM E-yield T06 4-Port USB 3.0 KVM Switch 2 PCs 1920x1080
Share four USB 3.0 devices between two computers with a single button press, supporting 1920x1080 video and requiring no external power supply
- TypeUSB
- Computer Connections4 Ports
- Monitor Connections4 Ports
- Video Resolution1920 x 1080
- PC SelectionManual Switch
- AutoScan Interval3 seconds
- Share 4 USB 3.0 peripherals between two computers
- Manual button switching with LED status indication
- Plug-and-play operation on Windows, Mac, Linux and Chrome OS
- Supports 1920 x 1080 video resolution at 150 MHz bandwidth
- Bus-powered design with optional 5 V micro-USB port for power-hungry devices
Two-Computer USB 3.0 Peripheral Sharing
The LUOM E-yield T06 lets two Windows, Mac or Linux computers share four USB 3.0 devices such as keyboards, mice, printers, scanners or flash drives. A single push-button with LED indication swaps control instantly without driver installation or network configuration. The unit is bus-powered and includes cables for immediate setup.
Passive Cooling and Zero Standby Power
With no internal fan or external power supply required, the switch adds no audible noise and draws negligible power while idle. Operating temperature range is 0 °C to 50 °C (32 °F to 122 °F) at up to 90 % non-condensing humidity, so it runs silently in typical office or home environments without thermal throttling.
Replaces Manual Cable Swapping for Four Devices
The switch eliminates the wear and clutter of repeatedly unplugging four USB 3.0 cables when moving between two workstations. It is not suited for users who need simultaneous access from both computers or who require video switching alongside USB sharing. The jump is worthwhile whenever two systems regularly share the same set of peripherals.
Highlights
- Share 4 USB 3.0 peripherals between two computers
- Manual button switching with LED status indication
- Plug-and-play operation on Windows, Mac, Linux and Chrome OS
- Supports 1920 x 1080 video resolution at 150 MHz bandwidth
- Bus-powered design with optional 5 V micro-USB port for power-hungry devices
Specifications
| Brand | LUOM |
|---|---|
| Series | E-yield T06 |
| Model | E-yield T06 |
| Type | USB |
| Computer Connections | 4 Ports |
| Monitor Connections | 4 Ports |
| Video Resolution | 1920 x 1080 |
| PC Selection | Manual Switch |
| AutoScan Interval | 3 seconds |
| Bandwidth | 150 MHz |
| Monitors Supported | VGA, SVGA and Multi-Sync |
| Temperature | 0ºC to 50ºC(32ºF to 122ºF) |
| Humidity | 0% to 90%,Non-Condensing |
| Power Features | Requires no additional power supply |
| USB Features | with USB support |
| SplitterOnly | Video Switch |
| Weight | 0.3 lbs |
| Package Contents | with Cables |
Questions about this item
How do I connect the LUOM E-yield T06 to two computers and four USB 3.0 devices using the included cables?
Connect each computer to the switch with the supplied USB cables, attach up to four peripherals to the front ports, then press the button to toggle between systems; the LED shows the active PC.
When should I add the optional 5 V power adapter to the micro-USB port on the LUOM E-yield T06?
Plug in a standard 5 V adapter only when bus power from the two computers is insufficient for high-draw devices such as external hard drives or SSDs.
What video resolution limit applies when using the LUOM E-yield T06 with VGA or SVGA monitors?
The switch supports up to 1920 x 1080 at 150 MHz bandwidth, so higher resolutions or refresh rates will not be passed through.
