Rectangular metal electronic ballast with wire leads and label

Lumapro

Lumapro 4KGE7 Electronic Ballast 117-231W 2-4 Lamps

SKU CH-QDS1-CXG7D

Electronic fluorescent ballast runs two to four T5 lamps at up to 55 watts each on 120 to 277 volt input

  • Powers two to four T5 fluorescent lamps reliably
  • Operates on 120 to 277 V AC input voltage
  • Programmed start extends lamp life in frequent cycling
  • Supports up to 55 W per lamp maximum
  • Meets California Title 20 efficiency requirements

What this ballast does

The Lumapro 4KGE7 electronic ballast operates fluorescent fixtures with programmed start on 120 to 277V AC input. It supports two, three or four T5 lamps at up to 55W each, delivering 117 to 231W total power. The unit is CA Title 20 compliant and rated for a minimum starting temperature of 0°F. It suits commercial or residential installations that need reliable, non-dimming fluorescent operation.

Verify your fixture before ordering

Confirm the fixture uses T5 lamps rated at or below 55W and that the lamp count is between two and four. Ensure the supply voltage falls within the 120 to 277V AC range. The ballast provides no dimming function, so it cannot be used with dimming controls. Check that the mounting footprint and wiring access match the existing housing. The product carries California Proposition 65 warnings for cancer and reproductive harm.

Build and daily use

The electronic design reduces audible hum and improves lamp life compared with magnetic alternatives. Programmed start reduces electrode stress during ignition, which helps extend lamp cycles in frequent-switching areas. Fixed-output operation means light level stays constant without additional controls. Wiring follows standard colour codes for line, neutral and lamp leads. The unit is new and ships as a direct replacement for compatible fixtures.

Highlights

  • Powers two to four T5 fluorescent lamps reliably
  • Operates on 120 to 277 V AC input voltage
  • Programmed start extends lamp life in frequent cycling
  • Supports up to 55 W per lamp maximum
  • Meets California Title 20 efficiency requirements

Specifications

BrandLUMAPRO

Questions about this item

What comes in the box and do I need to buy T5 lamps separately?

The ballast is supplied as a single unit; T5 fluorescent lamps up to 55 W each are not included and must be purchased separately.

Which lamp configuration does the 117–231 W range cover?

The ballast supports two, three or four T5 lamps with a maximum of 55 W per lamp, so the total wattage depends on how many lamps you install.

What does the 120–277 V input voltage mean for my installation?

It operates on any supply between 120 V and 277 V AC, making it compatible with standard North American commercial and residential circuits.
